The PLX81-EIP-61850 is an industrial protocol gateway manufactured by ProSoft Technology that enables bi-directional communication between Intelligent Electronic Devices on an IEC 61850 network and Programmable Automation Controllers on an EtherNet/IP network. The gateway operates as an EtherNet/IP server supporting both Class 1 and Class 3 messaging services. It features primary data transfer through Class 1 server connections supporting up to 10 implicit I/O connections, and can communicate with up to 2 additional EtherNet/IP clients using Class 3 messaging services. The IEC 61850 client interface can obtain data from up to 20 IED devices on a 61850 network. The gateway includes one physical Ethernet port, requiring both protocols to operate on the same subnet. This product has been discontinued and replaced by the PLX82-EIP-61850 model as of March 2020.
Item Details
- Brand Name: ProSoft
- Manufacturer: ProSoft Technology, Inc.
- Item Type Name: EtherNet/IP to IEC 61850 Protocol Gateway
- Product Family / Series: PLX80 Series
Product Specifications
- power_supply: 24 V DC nominal
- power_input_range: 10-32 V DC
- current_consumption_24vdc: 200 mA maximum
- current_consumption_32vdc: 150 mA maximum
- current_consumption_10vdc: 450 mA maximum
- ethernet_ports: 1
- ethernetip_class_1_connections: 10
- ethernetip_class_3_clients: 2
- iec_61850_ied_devices: 20
- mounting: DIN-rail
Additional Details
- Lifecycle Status: Discontinued (replaced by PLX82-EIP-61850 effective March 2020)
