Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony iPC |
| Product or Component Type | PC panel |
| Processor name | Atom N270 1.66 GHz L2 cache 512 KB |
| Chipset type | Intel 945GME 533 MHz |
| Display size | 19 inch |
| Display colour | 16 million colours |
| Luminance | 27.9 fc (300 cd/m²) |
| Drive type | DVD-RW |
| Video controller type | Intel Graphics Media Accelerator (GMA) 950, 224 MB |
| Operating system | MS Windows XP Professional Edition SP3multi-language |
| Software package | Vijeo Designer run time demo |
| Bezel material | Aluminium alloy |
Complementary
| Characteristic | Value(s) |
|---|---|
| Terminal type | Touchscreen display |
| Data storage equipment | 500 GB enterprise hard disk |
| Display Type | Active matrix colour TFT LCD with LED backlight |
| Display Resolution | 1280 x 1024 pixels SXGA |
| View angle horizontal x vertical | 160 x 100° |
| Touch panel | Analogue resistive |
| Memory type | 512 KB SRAM 2 GB RAM DDR3 |
| type of cooling | Fanless |
| Integrated connection type | 2 Ethernet TCP/IP - RJ45 DVI-I video port - DVI-I COM1 serial link - male SUB-D 9 - RS232C 115 kbit/s) COM2 serial link - male SUB-D 9 - RS232C 115 kbit/s) 5 USB 2.0 type A 480 Mbit/s) |
| Port Ethernet | 10BASE-T/100BASE-T/1000BASE-T |
| Number of slots | 1 PCI 1 PCI express 4x |
| [Us] rated supply voltage | 100...240 V AC power supply |
| Supply voltage limits | 85â¦265 V |
| Network frequency | 50-60 Hz 47...63 Hz |
| Line Rated Current | 1.6 A |
| Inrush current | 40 A |
| Power Consumption in W | 130 W |
| Material | Treated steel |
| Display material | Polyethylene sheet |
| Fixing mode | Enclosure door by fixing kit fasteners included) Panel by fixing kit fasteners included) |
| Type of Installation | Indoor |
| Control type | ON/OFF push-button equipment ON and OFF) Push-button reset) |
| Local signalling | LED (multi-colour) for power LED (yellow) for accessing hard disk (DISK) |
| Width | 18.9 in (480 mm) |
| Height | 15.0 in (380 mm) |
| Depth | 6.02 in (153 mm) |
| Cut-out dimensions | 459.5 (+/- 0.5) x 359.5 (+/- 0.5) x 1.6...10 mm |
| Product Weight | 34.15 lb(US) (15.49 kg) |
| Main type | Universal |
