The SICK FX3-XTIO84002 is a safety-rated input/output expansion module for the Flexi Soft safety controller system. This module provides 8 safety inputs, 2 test outputs, and 4 safe outputs, allowing flexible integration of safety sensors and actuators in industrial machinery and automated guided vehicles. The module is configured via Flexi Soft Designer or Safety Designer software and operates on the FLEXBUS+ communication architecture. It achieves the highest safety ratings: SIL 3 per IEC 61508, Category 4 per EN ISO 13849, and Performance Level e. The device features PNP semiconductor outputs with short-circuit protection, spring terminal connections for reliable wiring, and fast shut-off capability with an 8 ms response time. It supports both single-channel and dual-channel output configurations with different safety performance characteristics.
Item Details
- Brand Name: Sick
- Manufacturer: SICK AG
- Item Type Name: Safety I/O Module
- Product Family / Series: Flexi Soft
- Part Number: FX3-XTIO84002
- Manufacturer Part Number: 1044125
Product Specifications
- module_type: I/O module
- number_of_safety_inputs: 8
- number_of_test_outputs: 2
- number_of_safe_outputs: 4
- safety_integrity_level: SIL 3 (IEC 61508), SILCL 3 (EN 62061)
- safety_category: Category 4 (EN ISO 13849)
- performance_level: PL e (EN ISO 13849)
- pfhd_single_channel: 4.8 x 10⁻⁹ per hour (EN ISO 13849)
- pfhd_dual_channel: 0.9 x 10⁻⁹ per hour (EN ISO 13849)
- mission_time: 20 years (EN ISO 13849)
- fast_shut_off_time: 8 ms
- configuration_method: Via software (Flexi Soft Designer, Safe EFI-pro System: Safety Designer)
- power_supply: Via FLEXBUS+
- internal_power_consumption: ≤ 2.2 W
- input_voltage_high: 13 V DC to 30 V DC
- input_voltage_low: -5 V DC to 5 V DC
- input_current_high: 2.4 mA to 3.8 mA
- input_current_low: -2.5 mA to 2.1 mA
- test_output_voltage_high: 15 V DC to 30 V DC
- test_output_current: ≤ 120 mA
- test_pulse_generators: 2
- output_voltage_supply: 24 V DC (16.8 V DC to 30 V DC)
- output_voltage_high: 16 V DC to 30 V DC
- output_current: ≤ 2 A
- output_type: PNP semiconductors, short-circuit protected
- supply_voltage_type: PELV or SELV
- protection_class: III (EN 61140)
- connection_type: Spring terminals
- flexi_loop_compatible: Yes
Additional Details
- Ecliss 9 0: 27249090
- Etim 5 0: EC002632
- Etim 6 0: EC002632
- Unspsc 16 0901: 32151705
Measurements
- Weight: 164 g (± 5%)
- Dimensions: 22.5 mm x 96.5 mm x 120.6 mm (W x H x D)
