The Omron FIS-0003-0003G is an ultra-compact MS-3 laser barcode scanner designed for embedded industrial automation applications. This fixed-mount 1D barcode reader features raster scanning with low-density optics, delivering high-speed read performance up to 1000 decodes per second. The scanner offers a wide 70-degree scan angle coupled with an IP54-rated enclosure for dust and splash protection. It is ideal for OEM integration into space-constrained instruments requiring reliable barcode reading. The device features flexible mounting options, adjustable optics, and can operate with PNP/NPN digital outputs. Visual LED indicators provide scanner performance confirmation. Its compact form factor and versatile configuration make it suitable for medical instruments, laboratory equipment, kiosks, and other automated systems requiring fast, accurate barcode scanning.
Item Details
- Brand Name: Omron
- Manufacturer: Omron Microscan Systems
- Item Type Name: Laser Barcode Scanner
- Product Family / Series: MS-3
Product Specifications
- scan_type: Raster
- optics_density: Low Density
- scan_angle: 70 degrees
- decode_rate: Up to 1000 decodes/second
- read_range: 51 to 254 mm (2 to 10 inches)
- laser_type: 1D Laser
- output_type: PNP/NPN Digital
- power_supply: 5 VDC ±5%, 200 mV p-p max ripple
- enclosure_rating: IP54
- cable_length: 3 ft (0.91 m) with High Density connector
Additional Details
- Certifications / Approvals: RoHS
