The Beckhoff EL3062 is a 2-channel analog input EtherCAT Terminal designed for precise voltage measurement in industrial automation applications. It processes single-ended analog signals in the range of 0 to 10 V with 12-bit resolution, presented as 16-bit data including sign. The voltage signals are digitized and transmitted with electrical isolation to higher-level automation devices via the EtherCAT fieldbus protocol. The terminal features reference ground as common ground potential for both input channels, LED indication of signal states, and robust construction for harsh industrial environments. It supports configurable signal processing with activatable FIR and IIR filters for noise suppression and includes limit value monitoring for automatic threshold checks. The module integrates seamlessly into distributed I/O systems with compact design and standard DIN-rail mounting.
Item Details
- Brand Name: Beckhoff
- Manufacturer: Beckhoff Automation
- Item Type Name: EtherCAT Terminal Analog Input Module
- Product Family / Series: EL3xxx EtherCAT Terminals
Product Specifications
- number_of_channels: 2
- input_type: Analog voltage, single-ended
- voltage_range: 0 to 10 V
- resolution: 12 bit (16 bit presentation with sign)
- measurement_error: <±0.3% of full scale
- conversion_time: 0.625 ms (default, 50 Hz filter)
- input_filter_frequency: 1 kHz
- electrical_isolation: 500 V
- current_consumption_e_bus: 130 mA typical
- connection_technology: EtherCAT
- dielectric_strength: 40 V max
Additional Details
- Lifecycle Status: Regular delivery
- Protection Rating: IP20
- Operating Temperature: -25 to +60 °C
- Storage Temperature: -40 to +85 °C
- Relative Humidity: Up to 95% (non-condensing)
- Vibration Shock Compliance: EN 60068-2-6, EN 60068-2-27
Measurements
- Weight: 60 g
