1 year warranty
The E-Mon Class 2000 E20-480400-JKIT is a revenue-grade three-phase electric submeter designed for monitoring energy consumption in commercial, industrial, and institutional facilities. This standalone kWh meter operates at 277/480 VAC with a 400 A current rating and supports both 3-wire and 4-wire three-phase configurations. The meter features a direct-read 2-line alphanumeric LCD display showing cumulative kWh and real-time kW load without multipliers. It includes three patented 0-2 VDC output split-core current transformers that allow safe installation without power interruption and remote sensor mounting up to 2000 feet from the meter. The unit comes in an industrial-grade JIC steel enclosure with padlocking hasp and mounting flanges for indoor installation. It provides pulse output communication and is certified to ANSI C12.20 accuracy standards with ±0.2% accuracy from 1% to 100% of rated load.
Item Details
- Brand Name: Honeywell
- Manufacturer: E-Mon (Honeywell)
- Item Type Name: Three-Phase kWh Electric Submeter
- Product Family / Series: Class 2000
- Model Number: E20-480400-JKIT
Product Specifications
- voltage: 277/480 V AC
- current: 400 A
- number_of_phases: 3
- phase_configuration: 3-wire or 4-wire
- frequency: 50 Hz
- ct_inputs: 3
- communication_protocol: Pulse output
- display_type: 2-line alphanumeric LCD, 8-digit
- accuracy: ±0.2% (1% to 100% of rated load)
- accuracy_standard: ANSI C12.20
- current_sensor_type: Split-core with 0-2 V DC output
- sensor_remote_distance: Up to 2000 feet
- enclosure_type: JIC steel
- enclosure_rating: Indoor use
- max_operating_temperature: 50 °C
Additional Details
- Certifications / Approvals: UL/cUL Listed
- Memory Type: Non-volatile
- Meter Grade: Revenue-grade
- Knockouts: 1-1/16 inch (3/4 inch conduit) bottom, 7/8 inch (1/2 inch conduit) top
- Enclosure Features: Padlocking hasp and mounting flanges
Measurements
- Height: 184 mm
- Width: 152 mm
- Depth: 76 mm
