The Vickers DG4V-3S-2C-M-U-B5-60 is a solenoid-operated directional control valve designed for industrial hydraulic applications. This D03 (NG6) size valve features a 4-way, 3-position configuration with a type 2C spool arrangement, providing spring-centered operation with all ports closed in the neutral center position. The valve operates with 110 VAC (50 Hz) or 120 VAC (60 Hz) power supply and includes an ISO 4400 (DIN 43650) electrical connector mounting. It is part of the DG4V-3S standard performance series, suitable for controlling hydraulic flow direction in manufacturing equipment, mobile machinery, and industrial automation systems. The Design 60 designation indicates the basic configuration with robust construction for reliable operation in demanding hydraulic circuits.
Item Details
- Brand Name: Vickers
- Manufacturer: Eaton
- Item Type Name: Solenoid Operated Directional Control Valve
- Product Family / Series: DG4V-3S Series
- Model Code: DG4V-3S-2C-M-U-B5-60
- Valve Size: D03 (NG6)
- Performance Type: Standard Performance
- Design Number: 60 (Basic)
- Mounting Interface: ISO 4401
Product Specifications
- valve_configuration: 4-way, 3-position
- spool_type: 2C (Closed Center - All Ports Blocked)
- spring_arrangement: Spring Centered
- maximum_operating_pressure: 350 bar (5075 psi)
- t_port_pressure_rating: 100 bar (1450 psi)
- maximum_flow_rate: 40 L/min (10.5 gpm)
- coil_voltage: 110 V AC (50 Hz) / 120 V AC (60 Hz)
- electrical_connection: ISO 4400 (DIN 43650)
- actuation_type: Double Solenoid
- fluid_viscosity_range: 36 cSt (168 SUS) at 50°C (122°F) typical
Additional Details
- Max Ambient Temperature: 70°C (158°F)
- Max Operating Temperature: 70°C (158°F)
- Mounting Type: Subplate or Manifold
- Manual Override: Plain overrides in solenoid ends
- Valve Application: Industrial Hydraulic Systems
Measurements
- Weight: 1.93 kg (4.25 lb)
- Overall Length: 200 mm (7.87 in)
- Width: 146 mm (5.75 in)
- Height: 45 mm (1.7 in)
