The Vickers DG4V-3-2A-MS-W-B-40 is a solenoid operated directional control valve designed for directing and stopping hydraulic fluid flow in industrial and mobile hydraulic systems. This CETOP 3 (NG6) size valve features a type 2A spool configuration with closed center functionality on all ports, providing precise control over actuator direction and load holding. The valve employs a spring offset end-to-end actuation arrangement and wet armature type solenoids for reliable switching. Suitable for subplate mounting on ISO 4401 interfaces, it is commonly applied in machine tools, material handling equipment, and mobile machinery where robust flow control and pressure handling are essential. The MS designation indicates standard performance with flow capacity up to 80 L/min, while the W-B-40 code specifies the electrical configuration with 110V AC 50Hz or 120V AC 60Hz coil voltage.
Item Details
- Brand Name: Vickers
- Manufacturer: Eaton Corporation
- Item Type Name: Solenoid Operated Directional Control Valve
- Product Family / Series: DG4V-3
- Model Code: DG4V-3-2A-MS-W-B-40
- Mounting Type: Subplate mounting
- Mounting Interface: ISO 4401 / CETOP 3 / NG6
- Spool Type: 2A - Closed center (all ports)
- Spool Spring Arrangement: A - Spring offset, end-to-end
- Solenoid Type: Wet armature
Product Specifications
- maximum_pressure_p_a_b: 350 bar
- maximum_pressure_t_port: 210 bar
- maximum_flow_rate: 80 L/min
- nominal_size: CETOP 3 / NG6
- voltage: 110V AC 50Hz / 120V AC 60Hz
- current_50hz: 0.64 A at 110V AC
- current_60hz: 0.54 A at 115-120V AC
- coil_part_number: 633741
- duty_cycle: Continuous (ED = 100%)
Additional Details
- Lifecycle Status: Discontinued by manufacturer
Measurements
- Weight: 2.27 kg (5.00 lbs)
