The Pilz PNOZ e1vp 774131 is a standalone configurable safety relay module designed for safety-related interruption of safety circuits in industrial automation applications. It supports single-channel or dual-channel wiring with or without detection of shorts across contacts. The module provides 2 semiconductor safety outputs (1 instantaneous and 1 delayed) plus 1 auxiliary output, operating on 24 V DC supply voltage. Applications include emergency stop monitoring, safety gate monitoring, limit switch monitoring, and light beam device monitoring Types 2 and 4. The relay features automatic or monitored manual reset, self-test capability, programmable delay-on de-energization timer with selectable times, and AND/OR logic inputs for connecting multiple units. It meets safety standards EN 60947-5-1, EN 60204-1, and VDE 0113-1, achieving SIL 3, PL e, and Category 4 safety ratings. The compact module has a width of 22.5 mm and uses plug-in screw terminals for easy installation and maintenance.
Item Details
- Brand Name: Pilz
- Manufacturer: Pilz GmbH & Co. KG
- Item Type Name: Safety Relay
- Product Family / Series: PNOZelog
- Sub Range: PNOZ e1vp
- Full Model Number: PNOZ e1vp 10/24VDC 1so 1so t
Product Specifications
- supply_voltage: 24 V DC
- supply_voltage_tolerance: -20% / +25%
- supply_voltage_range: 19.2-30 V DC
- power_consumption_no_load: 2 W
- residual_ripple: 20%
- number_of_inputs: 2
- input_voltage: 24 V DC
- input_current: 5 mA
- number_of_safety_outputs: 2
- number_of_instantaneous_safety_outputs: 1
- number_of_delayed_safety_outputs: 1
- number_of_auxiliary_outputs: 1
- number_of_test_pulse_outputs: 2
- output_type: Semiconductor technology
- output_switching_capability_at_UB_≤_26.5V: 2 A / 50 W
- output_switching_capability_at_UB_>_26.5V: 1.5 A / 45 W
- overall_external_loading_semiconductor: 130 W
- selectable_delay_times: 0 s, 0.15 s, 0.5 s, 1 s, 2 s, 3 s, 5 s, 7 s, 10 s
- stop_category: 0/1
- terminal_type: Screw terminal
- terminal_style: Plug-in
- operating_modes: Single-channel, Dual-channel, Automatic reset, Monitored manual reset, Start-up testing, Self-test, Detection of shorts across contacts, AND/OR logic inputs
- safety_integrity_level: SIL 3
- performance_level: PL e
- safety_category: Category 4
- protection_rating: IP40
Additional Details
- Certifications / Approvals: CE, cULus Listed, EAC (Eurasian), TÜV, CCC
- Product Standards: EN 60947-5-1, EN 60204-1, EN 62061, EN ISO 13849-1, VDE 0113-1, VDE 0116, DIN V VDE 801-1/A1
- Application Options: Instantaneous E-STOP monitoring, Delayed E-STOP monitoring, Safety gate monitoring, Limit switch monitoring, Light beam device monitoring Type 2 (with/without test pulse), Light beam device monitoring Type 4, Safe delay-on de-energization timer
- Environment: Industrial environment
- Duty Cycle: 100%
Measurements
- Weight: 130 g
- Width: 22.5 mm
- Height: 94 mm
- Depth: 121 mm
