The Pilz 751110 PNOZ s10 C is a contact expansion module designed for use with PNOZsigma safety relays. It provides 4 normally open and 1 normally closed safety contacts to expand the output capacity of base safety relay units with feedback loop monitoring. The module operates on 24 V DC supply voltage and features a switching capacity of 12 A DC1, making it suitable for high-current safety applications. With plug-in spring-loaded terminals and a compact 45 mm width design, it enables rapid assembly on DIN rail mounting systems. The unit meets EN 60947-5-1 and EN 60204-1 standards and is used in industrial safety circuits where additional safety contacts are required for machine control and emergency stop functions.
Item Details
- Brand Name: Pilz
- Manufacturer: Pilz GmbH & Co. KG
- Item Type Name: Safety Relay Contact Expansion Module
- Product Family / Series: PNOZsigma
- Model Number: PNOZ s10 C 24VDC 4 n/o 1 n/c
- Part Number: 751110
- Gtin: 4046548025484
Product Specifications
- supply_voltage: 24 V DC
- outputs: 4 normally open (N/O), 1 normally closed (N/C)
- switching_load: 12 A DC1
- switching_capacity_dc: 300 W
- contact_voltage_ac: 240 V AC
- contact_voltage_dc: 24 V DC
- contact_material: Silver tin oxide
- coil_resistance: 30 Ω
- number_of_channels: 2 (Dual-channel)
- safety_category_iso_13849_1: Category 4
- performance_level_iso_13849_1: PL e
- terminal_type: Plug-in spring-loaded terminals (cage clamp)
- mounting_type: DIN rail (35 mm)
Additional Details
- Country of Origin*: Germany
- Standards Compliance: EN 60947-5-1, EN 60204-1, VDE 0113-1
- Function: Contact expansion module for safety relays with feedback loop monitoring
- Application: Used to increase the number of instantaneous safety contacts available on base units in safety circuits
*Country of origin may vary.
Measurements
- Weight: 301.8 g
- Width: 45 mm
- Height: 98 mm (with spring-loaded terminals) / 100 mm
- Depth: 120 mm
