The SIMATIC HMI MTP1000 Unified Basic Panel is a 10-inch widescreen operator interface designed for industrial automation and process control applications. It features a TFT touch display with 1280 x 800 pixel resolution and 16 million colors, providing clear visualization of machine status and process data. The panel supports PROFINET communication for integration with Siemens control systems and includes two USB 2.0 interfaces for data transfer and configuration. Configurable from WinCC Unified Basic V18 Update 3 or later, it offers intuitive engineering and runtime functionality. The panel is suitable for applications requiring compact HMI solutions with touch-based operation, including manufacturing equipment, packaging lines, and process monitoring systems. It includes open-source software on Blu-ray and mounting hardware in the delivery scope.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: Human Machine Interface Panel
- Product Family / Series: SIMATIC HMI Unified Basic Panels
- Model: MTP1000
- Article Number: 6AV2123-3KB32-0AW0
- Ean: 4034106035204
Product Specifications
- display_type: LCD TFT
- display_size: 10.1 inch widescreen
- display_active_area: 217.0 x 135.6 mm
- display_resolution: 1280 x 800 pixels
- display_colors: Up to 16.7 million
- touch_operation: Yes
- backlighting_mtbf: 20000 h at 25°C
- backlight_dimmable: Yes, 10-100%
- ram: 2 GB LPDDR4-SDRAM
- internal_flash_memory: 10 GB eMMC pSLC
- configuration_memory: 256 MB
- user_memory: 10 MB
- profinet_interface: 1
- usb_interfaces: 2 x USB 2.0
- supported_protocols: TCP/IP, MODBUS, EtherNet/IP
- power_supply: 19.2-28.8 V DC
- configuration_software: WinCC Unified Basic V18 Update 3 or later
Additional Details
- Country of Origin*: China
- Hs Code: 85371091
- Scope Of Delivery: Panel, open-source software on Blu-ray, mounting materials
*Country of origin may vary.
Measurements
- Weight: 1.55 kg
