ABB

2CDL220001R3058 ABB - PS2/58/30

Technical

Suitable For:
S200
F200
DDA200
S200
F200
DDA200
Suitable for Product Class:
2-pole devices (L1+N)
Pitch:
17.6
Number of Poles:
58P
Number of Phases:
2-phase
Number of Mountable Devices:
29
Number of Terminals (Nterm):
58
Accessory Type:
Busbar
Connection Type:
Pin
Rated Cross-Section:
30 mm²

Electrical

Rated Operational Voltage:
230 / 400 V AC
Maximum 690 V
230 / 400 V AC
Maximum 690 V
Rated Short-time Withstand Current Low Voltage (Icw):
25 kA
Rated Uninterrupted Current (Iu):
120 A
Rated Frequency (f):
50 / 60 Hz
Overvoltage Category:
III

Design

RAL Number:
RAL 7035 - Light Grey
Color:
grey

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
20230517
REACH Information:
False - does not contain substances > 0.1 mass percentage
REACH Date:
20240821
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
4. Large Equipment (Any External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Business

Environmental

Pollution Degree:
2
Environmental Information:

Dimensions

Width in Number of Modular Spacings:
58.0
Product Net Width:
15.1 mm
Product Net Height:
42 mm
Product Net Depth / Length:
1020 mm
Product Net Weight:
1.81 kg

Ordering

Package Level 1 Units:
carton 10 piece
Package Level 1 Gross Weight:
9.57 kg

Certificates and Declarations

Installation

Popular Downloads

External Classifications and Standards

ETIM 9:
EC000215 - Phase busbar
ETIM 10:
EC000215 - Phase busbar
UNSPSC:
39121117
eClass:
V11.0 : 27371306
IDEA Granular Category Code (IGCC):
4378 >> Phase busbar
Object Classification Code:
W
Standards:
IEC/EN 60947-1
