1SDA100550R1 ABB - XT5N 400 BREAKING PART 3p F F

ABB EcoSolutions

ABB EcoSolutions:
Yes
ABB Site Meeting Group Waste To Landfill Target:
UL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions:
Recyclability Rate of the Product acc. to EN45555:
Design for Closing Resource Loops - Standard EN45555 - 59.6 %

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
6ec8fe9c-35cc-465d-820a-ddaa8f459a25 Italy
Simplified SCIP:
c8c90e9d-7c70-4379-96fd-a9ae6e6f1300 Germany
d0900ff7-a757-4fae-a881-a5ea25351c51 Germany
9b07e73f-14d1-4af1-9110-b8729f7402a2 France
1ad62dc8-d90d-4210-b193-abc6073a67d1 Netherlands
4b23fb89-fe2c-4410-bb42-7289f5302151 Spain
c9ce231f-a540-402b-914b-56397cad868a Netherlands
3a1436a8-4a07-462c-8f47-ffbf4c6edb63 Bulgaria
4978c3e4-b48b-4753-98bb-afdbf6490a07 Sweden
5fc59b9e-999c-48b4-a1e4-ec0f65261b4f Poland
7fbd870b-b6ac-4dbd-96ee-efc6241fb2dd France
80841d8b-b4a7-45a3-9c5b-6b33269890f7 Sweden
41f6ce1e-07b4-4cef-a89d-70321e8d8e4b Greece
c62e49f2-6aaf-4fec-bf1a-29b933eff264 Germany
e8c252fe-cd80-4dc9-8ab0-2c27501bb96e Poland
e6573a9b-6cca-49ba-9817-a8923496bfa5 Norway
9dab5e1f-6113-4646-86e3-0641a27ce089 Finland
c65804ad-6e27-4de9-aa6e-595f51ec3530 Netherlands
a58a46b9-21ca-4071-b3f6-13ce22ee89b5 Germany
6fe5a1fb-9b7a-4954-b0d0-677b146c7b46 Denmark
8806fe7b-7636-410b-bf82-b3ea05db2540 Germany
919307d7-d6a1-4434-89eb-f8f18f607211 Croatia
cc802dfa-0019-40e3-b63b-909338aacc7f Czech Republic
3fd922df-49c8-4629-942f-1424b724d3d6 Poland
fcf12145-12f8-489d-a1a2-5d2f5cec55bb Netherlands
b5ce3e0b-1e9a-4aa0-bf4a-de0568d473b2 Netherlands
bd70af9c-c0f3-4891-9472-e1c6ef509af2 Estonia
63900ef9-165f-457b-ac78-dafa3ba146d1 Portugal
c8c90e9d-7c70-4379-96fd-a9ae6e6f1300 Germany
d0900ff7-a757-4fae-a881-a5ea25351c51 Germany
9b07e73f-14d1-4af1-9110-b8729f7402a2 France
1ad62dc8-d90d-4210-b193-abc6073a67d1 Netherlands
4b23fb89-fe2c-4410-bb42-7289f5302151 Spain
c9ce231f-a540-402b-914b-56397cad868a Netherlands
3a1436a8-4a07-462c-8f47-ffbf4c6edb63 Bulgaria
4978c3e4-b48b-4753-98bb-afdbf6490a07 Sweden
5fc59b9e-999c-48b4-a1e4-ec0f65261b4f Poland
7fbd870b-b6ac-4dbd-96ee-efc6241fb2dd France

Environmental

Environmental Information:

Ordering

E-Number (Finland):
3641396
E-Number (Norway):
4380323
EAN:
8056221006262
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85389099

Dimensions

Product Net Width:
140 mm
Product Net Height:
205 mm
Product Net Depth / Length:
103.5 mm
Product Net Weight:
3.425 kg

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
248 mm
Package Level 1 Height:
240 mm
Package Level 1 Depth / Length:
285 mm
Package Level 1 Gross Weight:
3.8 kg
Package Level 1 EAN:
8056221006262

Additional Information

Product Main Type:
SACE Tmax XT
Product Name:
Moulded Case Circuit Breaker
Product Type:
Breaking Part
Version:
F

Technical

Electrical Durability:
7000 cycle
60 cycles per hour
7000 cycle
60 cycles per hour
Mechanical Durability:
20000 cycle
120 cycles per hour
20000 cycle
120 cycles per hour
Number of Poles:
3P
Order Multiple:
1 piece
Rated Impulse Withstand Voltage (Uimp):
8 kV
Rated Insulation Voltage (Ui):
1000 V
Rated Operational Voltage:
690 V AC
750 V DC
690 V AC
750 V DC
Rated Service Short-Circuit Breaking Capacity (Ics):
(220 V AC) 70 kA
(230 V AC) 70 kA
(240 V AC) 70 kA
(380 V AC) 36 kA
(415 V AC) 36 kA
(440 V AC) 36 kA
(500 V AC) 25 kA
(525 V AC) 25 kA
(690 V AC) 20 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 2 Poles in Series 25 kA
(220 V AC) 70 kA
(230 V AC) 70 kA
(240 V AC) 70 kA
(380 V AC) 36 kA
(415 V AC) 36 kA
(440 V AC) 36 kA
(500 V AC) 25 kA
(525 V AC) 25 kA
(690 V AC) 20 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Short-time Withstand Current Low Voltage (Icw):
5 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(220 V AC) 70 kA
(230 V AC) 70 kA
(240 V AC) 70 kA
(380 V AC) 36 kA
(415 V AC) 36 kA
(440 V AC) 36 kA
(500 V AC) 25 kA
(525 V AC) 25 kA
(690 V AC) 20 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 2 Poles in Series 25 kA
(220 V AC) 70 kA
(230 V AC) 70 kA
(240 V AC) 70 kA
(380 V AC) 36 kA
(415 V AC) 36 kA
(440 V AC) 36 kA
(500 V AC) 25 kA
(525 V AC) 25 kA
(690 V AC) 20 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Uninterrupted Current (Iu):
400 A
Short-Circuit Performance Level:
N
Standards:
IEC60947-2
Sub-type:
XT5
Terminal Connection Type:
Front

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification Code:
Q
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409
Price on request
