The Danfoss VLT 6008 is a three-phase variable frequency drive (VFD) from the VLT 6000 HVAC series, designed specifically for heating, ventilation, and air conditioning applications. This drive operates on 380-460V AC power supply and provides precise motor speed control with a typical shaft output power of 5.5 kW (7.5 HP). It features integrated DC link reactors for harmonic suppression, electronic thermal motor protection, and programmable digital and analog inputs for flexible control strategies. The VLT 6008 incorporates automatic energy optimization to reduce power consumption and includes built-in RFI filtering to meet EMC standards. The drive supports serial communication protocols and offers multiple enclosure options including IP20, IP54, and NEMA rated configurations for various installation environments.
Item Details
- Brand Name: Danfoss
- Manufacturer: Danfoss
- Item Type Name: Variable Frequency Drive (AC Drive)
- Product Family / Series: VLT 6000 HVAC
- Model Designation: VLT 6008
Product Specifications
- input_voltage: 3-phase 380-460 V AC ±10%
- input_frequency: 50/60 Hz
- output_power: 5.5 kW (7.5 HP)
- continuous_output_current_380_440V: 13.0 A
- continuous_output_current_441_460V: 11.0 A
- max_output_current_60s_380_440V: 14.3 A
- max_output_current_60s_441_460V: 12.1 A
- output_power_kVA_400V: 9.3 kVA
- output_power_kVA_460V: 8.8 kVA
- frequency_range: 0-1000 Hz
- overload_capacity: 160% for 60 seconds
- power_factor: 0.90-1.0 at rated load
- ambient_temperature_operation: 0-45°C (IP20 bookstyle)
- max_relative_humidity: 95% non-condensing
- control_inputs: 8 digital inputs, 3 analog inputs (voltage/current)
Additional Details
- Lifecycle Status: Inactive (discontinued, no longer in production)
- Certifications / Approvals: CE marked, UL/cUL listed
- Communication Protocols: RS-485, optional PROFIBUS
- Protection Features: Electronic thermal relay (ETR), overvoltage, undervoltage, short circuit, ground fault
Measurements
- Weight: 10.5 kg
