The Danfoss 132F0020 is a compact VLT Micro Drive FC-51 variable frequency drive designed for controlling three-phase AC motors up to 1.5 kW (2.0 HP). This general-purpose frequency converter accepts three-phase 380-480 VAC input and delivers adjustable output frequencies from 0 to 200 Hz, making it suitable for industrial automation and HVAC applications. The drive features an IP20 chassis enclosure without a local control panel, RFI Class A1/B (C1) EMC compliance, and an integrated brake chopper for dynamic braking. Built with coated PCBs for operation in harsh environments, the drive includes electronic thermal motor protection, optimal heat dissipation, and supports side-by-side mounting without derating. The compact M2 frame size measures 176 mm (H) x 75 mm (W) x 168 mm (D), and it offers comprehensive I/O capabilities including 2 analog inputs, 1 analog output, 5 digital inputs, 1 pulse input, 1 thermistor input, and 1 relay output (240 VAC, 2A).
Item Details
- Brand Name: Danfoss
- Manufacturer: Danfoss
- Item Type Name: Variable Frequency Drive
- Product Family / Series: VLT Micro Drive
- Series: FC-51
- Model Code: FC-051P1K5T4E20H3BXCXXXSXXX
- Frame Size: M2
Product Specifications
- power_rating_normal_duty: 1.5 kW / 2.0 HP
- input_voltage: 380-480 V AC
- input_phases: 3-phase
- rated_current: 3.7 A
- input_frequency: 50-60 Hz
- output_frequency_range: 0-200 Hz
- enclosure_rating: IP20 / Chassis
- emc_class: RFI Class A1/B (C1)
- brake_chopper: Built-in
- analog_inputs: 2
- analog_outputs: 1
- digital_inputs: 5
- pulse_inputs: 1
- thermistor_inputs: 1
- relay_output: 1 (240 V AC, 2 A)
- control_panel: Not included
Additional Details
- Lifecycle Status: Last time buy June 30, 2026
- Pcb Coating: Coated (varnished cards)
- Compliance: RoHS Directive compliant
- Ean: 5702427357563
Measurements
- Weight: 1.8 kg
- Dimensions: 176 mm (H) x 75 mm (W) x 168 mm (D)
- Net Weight: 1.794 kg
- Gross Weight: 2.16 kg
- Volume: 4.611 L
