PSTX170-600-70 Softstarter - 170 A - 208 ... 600 V AC. The softstarter PSTX170-600-70 has a rated maximum operational current of 170 A with an operating voltage span from 208...600 V AC. The rated control voltage is between 100...250 V AC at 50/60 Hz.
Unity processor - 8 racks (12 slots) / 16 racks (4/6/8 slots) - 1900 mA, 5 V DC
Standard Models (0-599 Hz) Without EMC Filter Part Number: Delta VFD1A5MS43ANSAA Nominal Input VAC: 480 Volts AC Input Range VAC: 460 Volts AC HP: .50 HP Amps (HD): 1.5A Amps (ND): 1.8A Input Phase : 3 PH Operator Controls: Sold Seperately, See Accessories Brake Type : DC Injection; Dynamic Braking Motor Control-Max Level: Open Loop Vector-(Sensorless Vector) Closed Loop: NO AC Line Regenerative: NO Dynamic Braking Trans: Included Enclosure Rating: IP20 Frame Size: A4 Height: 5.04 Inches Width: 2.68 Inches Depth: 5.08 Inches Net Weight: 4 Lbs. Delta’s MS300 series is a standard compact vector control drive that inherits Delta’s superior drive technology. It supports both IM and PM motor control for application flexibility and provides STO safety mechanism. Also built-in various essential functions, including PLC capacity for simple programming needs, a communication slot for various communication cards, and a USB port to make data uploads and downloads fast and easy. Saving space, reducing setup and wiring time, while providing high efficiency and stability system, all included in the MS300 series with drive size reduced up to 40%. Delta VFD MS300 Micro Drive Accessories
The C2000 Plus Series features precise speed, torque and position control functions that are suitable for both sensor and sensorless synchronous / asynchronous motors. Features Include: Advanced Drive Controls For both synchronous and asynchronous motors | Dual rating design (heavy duty / super heavy duty) | Speed / torque / position control mode Versatile Drive Controls Built-in PLC function | Built-in brake unit | Supports various network protocols | Position control Environmental Adaptability Built-in DC reactor | Built-in EMC filter | 50˚C operating temperature Modular Design Hot pluggable LCD keypad | I/O extension cards | Various PG (encoder) feedback cards | Network cards for fieldbus modules | Removable fan Others Fast Response to Impact Load | A Drive for Permanent Magnet (PM) Motors | High-Performance Field-oriented Control | Auto Energy-Saving Operation | Deceleration Energy Backup (DEB) | Drive System Management Platform
The C2000 Plus Series features precise speed, torque and position control functions that are suitable for both sensor and sensorless synchronous / asynchronous motors. 460 V – 3 Phase 3.7 kW – 5 HP – 9 Amps
10.1” (1024 * 600) 65,536 Colors TFT Cortex-A8 800MHz CPU 512 MB RAM 256 MB ROM Built-in Ethernet interface 2 set of COM ports / 1 extension COM port USB Host USB Client Supports SD card
Acti9 iID - Residual Current Circuit Breaker - 2P - 63A - 30mA - B-SI type
Performance Power Supply, 24-28V DC, 960 W, 3-Phase 480V AC wide range / 600V DC Input Voltage, 40A
