Main
| Characteristic | Value(s) |
|---|---|
| Product or Component Type | Connector kit for EtherCAT |
| Accessory / Separate Part Type | Connector |
| Accessory / separate part category | Connection accessories |
| Accessory / separate part destination | Connector for EtherCAT cable |
Complementary
| Characteristic | Value(s) |
|---|---|
| Range Compatibility | Lexium 32i Lexium ILS Lexium ILA Lexium ILE |
| Product compatibility | Drive control unit LXM32i EtherCAT IL.2 |
| Communication interface | EtherCAT |
| Kit composition | 2 male connectors M12 4 pins (D-coded) 1 protective cap M12 |
| Product Weight | 0.223 lb(US) (0.101 kg) |
Main
| Characteristic | Value(s) |
|---|---|
| Product or Component Type | Connector kit for DeviceNet |
| Accessory / Separate Part Type | Connector |
| Accessory / separate part category | Connection accessories |
| Accessory / separate part destination | Connector for DeviceNet cable |
Complementary
| Characteristic | Value(s) |
|---|---|
| Range Compatibility | Lexium ILS Lexium ILE Lexium ILA |
| Product compatibility | IL.2 |
| Communication interface | DeviceNet |
| Kit composition | 1 female connector M12 5 pins (A-coded) |
| Product Weight | 0.2 lb(US) (0.1 kg) |
This product is part of the Lexium ILA, ILE, ILS range, an offer of inserts for motion control. The communication interface insert provides two STO signals. It is furnished with 4-pin female M8 connector for connection of signals and 1 4-pin male M8 connector for connection of signals. It weighs 0.027kg. It is suitable for printing, paper, packaging, handling, labelling, textile industry, electronics manufacture and medical technology applications. It is compatible for use with Lexium integrated drives. The kit includes 1 sealing insert and 1 insert with connectors. Lexium integrated drives integrate motor, positioning controller, power electronics, Fieldbus and safety function in a single device. Integrated drives for motion control with stepper, servo or brushless DC motor.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Lexium integrated drive |
| Product or Component Type | Insert for communication interface |
| Accessory / Separate Part Type | Connection accessories |
| Accessory / separate part category | Connection accessories |
| Accessory / separate part destination | For drives |
Complementary
| Characteristic | Value(s) |
|---|---|
| Electrical connection | 1 female connector M8 4 pins for connection of signals for safe torque off 1 male connector M8 4 pins for connection of signals for safe torque off |
| Kit composition | 1 sealing insert 1 insert with connectors |
| Input/output type | 2 STO signals |
| Product Weight | 0.060 lb(US) (0.027 kg) |
Main
| Characteristic | Value(s) |
|---|---|
| Product or Component Type | Connector kit for Modbus TCP |
| Accessory / Separate Part Type | Connector |
| Accessory / separate part category | Connection accessories |
| Accessory / separate part destination | Connector for Modbus TCP cable |
Complementary
| Characteristic | Value(s) |
|---|---|
| Range Compatibility | Lexium ILS Lexium ILE Lexium ILA |
| Product compatibility | IL.2 |
| Communication interface | Modbus TCP |
| Kit composition | 1 female connector M12 4 pins (D-coded) |
| Product Weight | 0.2 lb(US) (0.1 kg) |
This Schneider Electric Zelio Logic SR2B compact smart relay / programmable controller uses a supply voltage of 12 volts direct current, has 12 inputs / outputs with screw-clamp terminals, has an integrated clock and LCD display. This compact programmable relay is ideal for management, remote control or monitoring of simple automation systems. It is suitable for both industrial and commercial applications. It has compact form-factor, allowing installation on DIN rail. It also offers simple programming, display and diagnosing of malfunctions display and navigation buttons. Simple ladder programming, adapted for non-specialists. Discovery package, coming with Zelio Soft programming software, the simplest way to learn and use this relay. Built-in EEPROM flash memory for data backup up to 10 years, easy-to-recover after a power shortage or incident. This product meets EN/IEC 61000-4-11, EN/IEC 60068-2-6 Fc, EN/IEC 61000-4-12, EN/IEC 61000-4-2 level 3, EN/IEC 61000-4-5, EN/IEC 61000-4-3, EN/IEC 61000-4-4 level 3, EN/IEC 60068-2-27 Ea and EN/IEC 61000-4-6 level 3 standards. Simple to select, install and program, Zelio Logic is suitable for all your applications. Flexible, it offers you the choice of 2 ranges, compact or modular, extendable and 2 programming languages (FBD or LADDER). Easy to use, Zelio Logic provides a real alternative to solutions based on cabled logic or specific cards.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Zelio Logic |
| Product or Component Type | Compact smart relay |
Complementary
| Characteristic | Value(s) |
|---|---|
| Local display | With |
| Number or control scheme lines | 0â¦240 ladder 0â¦500 FBD |
| Cycle time | 6â¦90 ms |
| Backup time | 10 years 77 °F (25 °C) |
| Clock drift | 12 min/year 32â¦131 °F (0â¦55 °C) 6 s/month 77 °F (25 °C) |
| Checks | Program memory on each power up |
| [Us] rated supply voltage | 12 V DC |
| Supply voltage limits | 10.4â¦14.4 V |
| Maximum supply current | 120 mA without extension) |
| Power dissipation in W | 1.5 W without extension |
| Reverse polarity protection | With |
| Discrete input number | 8 IEC 61131-2 Type 1 |
| Discrete input type | Resistive |
| Discrete input voltage | 12 V DC |
| Discrete input current | 4 mA |
| Counting frequency | 1 kHz discrete input |
| Voltage state 1 guaranteed | >= 7 V IB...IG used as discrete input circuit >= 5.6 V I1...IA and IH...IR discrete input circuit |
| Voltage state 0 guaranteed | <= 3 V IB...IG used as discrete input circuit <= 2.4 V I1...IA and IH...IR discrete input circuit |
| Current state 1 guaranteed | >= 2 mA I1...IA and IH...IR discrete input circuit) >= 0.5 mA IB...IG used as discrete input circuit) |
| Current state 0 guaranteed | <= 0.2 mA IB...IG used as discrete input circuit) <= 0.9 mA I1...IA and IH...IR discrete input circuit) |
| Input compatibility | 3-wire proximity sensors PNP discrete input |
| Analogue input number | 4 |
| Analogue Input Type | Common mode |
| Analogue input range | 0...10 V 0...12 V |
| Maximum permissible voltage | 14.4 V analogue input circuit |
| Analogue input resolution | 8 bits at maximum voltage |
| LSB value | 39 mV analogue input circuit |
| Conversion time | Smart relay cycle time analogue input circuit |
| Conversion error | +/- 5 % 77 °F (25 °C) analogue input circuit +/- 6.2 % 131 °F (55 °C) analogue input circuit |
| Repeat accuracy | +/- 2 % 131 °F (55 °C) analogue input circuit |
| Operating distance | 10 m between stations, with screened cable (sensor not isolated) analogue input circuit |
| Input impedance | 14 kOhm IB...IG used as analogue input circuit 14 kOhm IB...IG used as discrete input circuit 2.7 kOhm I1...IA and IH...IR discrete input circuit |
| Number of Outputs | 4 relay |
| Output voltage limits | 24...250 V AC relay output) 5...30 V DC relay output) |
| Contacts type and composition | NO relay output |
| Output thermal current | 8 A for all 4 outputs relay output |
| Electrical durability | AC-12 500000 cycles 230 V, 1.5 A relay output IEC 60947-5-1 AC-15 500000 cycles 230 V, 0.9 A relay output IEC 60947-5-1 DC-12 500000 cycles 24 V, 1.5 A relay output IEC 60947-5-1 DC-13 500000 cycles 24 V, 0.6 A relay output IEC 60947-5-1 |
| Switching capacity in mA | >= 10 mA 12 V relay output) |
| Operating rate in Hz | 0.1 Hz at Ie)relay output 10 Hz no load)relay output |
| Mechanical durability | 10000000 cycles relay output |
| [Uimp] rated impulse withstand voltage | 4 kV EN/IEC 60947-1 and EN/IEC 60664-1 |
| Clock | With |
| Response time | 10 ms from state 0 to state 1)relay output 5 ms from state 1 to state 0)relay output |
| Connections - terminals | Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) semi-solid Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) solid Screw terminals, 1 x 0.25...1 x 2.5 mm² AWG 24...AWG 14) flexible with cable end Screw terminals, 2 x 0.2...2 x 1.5 mm² AWG 24...AWG 16) solid Screw terminals, 2 x 0.25...2 x 0.75 mm² AWG 24...AWG 18) flexible with cable end |
| Tightening torque | 4.4 lbf.in (0.5 N.m) |
| Overvoltage category | III conforming to IEC 60664-1 |
| Product Weight | 0.55 lb(US) (0.25 kg) |
modular smart relay Zelio Logic - 10 I O - 24 V DC - clock - display
digital input module - 12I - 24V DC sink - 1 wire
plastic safety switch XCSTE - 2NC - slow break - 1 entry tapped 1/2" NPT -24V
plastic safety switch XCSTE - 1NC + 1NO - slow break - 1 entry tapped Pg 11-24 V
plastic safety switch XCSTE - 1NC + 1NO - slow break - 1 entry tapped M16- 24V
plastic safety switch XCSTE - 2 NC - slow break - 1entry tapped M16 - 24 V
plastic safety switch XCSTE - 1NC+1NO- slow break- 2 entries tapped Pg 11 - 24V
plastic safety switch XCSTE - 2 NC - slow break - 1 entry tapped Pg 11 - 24 V
This Schneider Electric Zelio Logic SR3 compact smart relay / programmable controller uses a supply voltage of 24 volts direct current, has 10 inputs / outputs with screw-clamp terminals. It has an integrated clock and LCD display. This compact smart relays / programmable controller is ideal for management, remote control or monitoring of simple automation systems. It is suitable for both industrial and commercial applications. It has compact form-factor, allowing installation on DIN rail. It also offers simple programming, display and diagnosing of malfunctions display and navigation buttons. Simple ladder programming, adapted for non-specialists. Discovery package, coming with Zelio Soft programming software, the simplest way to learn and use this relay. Built-in EEPROM flash memory for data backup up to 10 years, easy-to-recover after a power shortage or incident. More I/O than SR2 model, for larger applications. Simple to select, install and program, Zelio Logic is suitable for all your applications. Flexible, it offers you the choice of 2 ranges, compact or modular, extendable and 2 programming languages (FBD or LADDER). Easy to use, Zelio Logic provides a real alternative to solutions based on cabled logic or specific cards.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Zelio Logic |
| Product or Component Type | Modular smart relay |
Complementary
| Characteristic | Value(s) |
|---|---|
| Local display | With |
| Number or control scheme lines | 0â¦500 FBD 0â¦240 ladder |
| Cycle time | 6â¦90 ms |
| Backup time | 10 years 77 °F (25 °C) |
| Clock drift | 12 min/year 32â¦131 °F (0â¦55 °C) 6 s/month 77 °F (25 °C) |
| Checks | Program memory on each power up |
| [Us] rated supply voltage | 24 V |
| Supply voltage limits | 19.2â¦30 V |
| Maximum supply current | 100 mA with extensions) 100 mA without extension) |
| Power dissipation in W | 3 W without extension 8 W with extensions |
| Reverse polarity protection | With |
| Discrete input number | 6 IEC 61131-2 Type 1 |
| Discrete input type | Resistive |
| Discrete input voltage | 24 V DC |
| Discrete input current | 4 mA |
| Counting frequency | 1 kHz discrete input |
| Voltage state 1 guaranteed | >= 15 V I1...IA and IH...IR discrete input circuit >= 15 V IB...IG used as discrete input circuit |
| Voltage state 0 guaranteed | <= 5 V I1...IA and IH...IR discrete input circuit <= 5 V IB...IG used as discrete input circuit <= 5 V |
| Current state 1 guaranteed | >= 1.2 mA IB...IG used as discrete input circuit) >= 2.2 mA I1...IA and IH...IR discrete input circuit) |
| Current state 0 guaranteed | <= 0.5 mA IB...IG used as discrete input circuit) <= 0.75 mA I1...IA and IH...IR discrete input circuit) |
| Input compatibility | 3-wire proximity sensors PNP discrete input |
| Analogue input number | 4 |
| Analogue Input Type | Common mode |
| Analogue input range | 0...10 V 0...24 V |
| Temperature probe type | NTC 10k 77 °F (25 °C) NTC 1000k 77 °F (25 °C) KTY81 210/220/221/222/250 Pt 500 |
| Maximum permissible voltage | 30 V analogue input circuit |
| Analogue input resolution | 8 bits |
| LSB value | 39 mV analogue input circuit |
| Conversion time | Smart relay cycle time analogue input circuit |
| Conversion error | +/- 5 % 77 °F (25 °C) analogue input circuit +/- 6.2 % 131 °F (55 °C) analogue input circuit |
| Repeat accuracy | +/- 2 % 131 °F (55 °C) analogue input circuit |
| Operating distance | 10 m between stations, with screened cable (sensor not isolated) analogue input circuit |
| Input impedance | 12 kOhm IB...IG used as analogue input circuit 12 kOhm IB...IG used as discrete input circuit 7.4 kOhm I1...IA and IH...IR discrete input circuit |
| Number of Outputs | 4 relay |
| Output voltage limits | 24...250 V AC relay output) 5...30 V DC relay output) |
| Contacts type and composition | NO relay output |
| Output thermal current | 8 A for all 4 outputs relay output |
| Electrical durability | AC-12 500000 cycles 230 V, 1.5 A relay output IEC 60947-5-1 AC-15 500000 cycles 230 V, 0.9 A relay output IEC 60947-5-1 DC-12 500000 cycles 24 V, 1.5 A relay output IEC 60947-5-1 DC-13 500000 cycles 24 V, 0.6 A relay output IEC 60947-5-1 |
| Switching capacity in mA | >= 10 mA 12 V relay output) |
| Operating rate in Hz | 0.1 Hz at Ie)relay output 10 Hz no load)relay output |
| Mechanical durability | 10000000 cycles relay output |
| [Uimp] rated impulse withstand voltage | 4 kV EN/IEC 60947-1 and EN/IEC 60664-1 |
| Clock | With |
| Response time | 10 ms from state 0 to state 1)relay output 5 ms from state 1 to state 0)relay output |
| Connections - terminals | Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) semi-solid Screw terminals, 1 x 0.2...1 x 2.5 mm² AWG 25...AWG 14) solid Screw terminals, 1 x 0.25...1 x 2.5 mm² AWG 24...AWG 14) flexible with cable end Screw terminals, 2 x 0.2...2 x 1.5 mm² AWG 24...AWG 16) solid Screw terminals, 2 x 0.25...2 x 0.75 mm² AWG 24...AWG 18) flexible with cable end |
| Tightening torque | 4.4 lbf.in (0.5 N.m) |
| Overvoltage category | III conforming to IEC 60664-1 |
| Product Weight | 0.55 lb(US) (0.25 kg) |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony GTU |
| Product or Component Type | Memory cartridge |
| Accessory / separate part category | Spare part |
| Accessory / separate part destination | Harmony GTU premium box |
Complementary
| Characteristic | Value(s) |
|---|---|
| Data storage equipment | 1 GB SD card |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony GTU |
| Product or Component Type | Protective cover |
| Accessory / separate part category | Protection accessory |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | HMIDT542 |
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony GTO |
| Product or Component Type | Cover |
| Accessory / separate part category | Protection accessory |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | HMIGTO2310 HMIGTO2300 |
| Accessory / separate part destination | Front panel screen |
Safety Module FOR PLC TM2xx, 1 FUNCTION, CAT3, SPRING TERMINALS
Additionnal EMC input filter - 3-phase supply - 25 A
modular smart relay Zelio Logic - 10 I O - 100..240 V AC - clock - display
Main
| Characteristic | Value(s) |
|---|---|
| Range compatibility | Lexium integrated drive ILT Lexium integrated drive ILP |
| Accessory / separate part type | Cable |
| Accessory / separate part category | Connection accessory |
| Product compatibility | ILT2V57.MB0A ILT2V85.MB0A ILT2V42.MB0A |
| Accessory / separate part destination | For Lexium integrated drive |
Complementary
| Characteristic | Value(s) |
|---|---|
| Communication interface | Pulse/direction |
| Product specific application | To set/program communication parameters |
| Cable length | 3.6 m |
| Electrical connection | 1 connector USB for PC 1 connector, 10 pins for integrated drive |
| Product weight | 0.133 kg |
This Magelis XBTZ is a RS 422 cable for connecting Magelis terminals to third-party PLCs. It enables connection of XBTGH and XBTGT terminals to Mitsubishi Melsec PLC with XBTZGCOM1 adaptor. It is equipped with one 9-way SUB-D connector at one end and one free end at the other end, it is 5 meters long.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XBT |
| Accessory / separate part category | Connection accessories |
| Accessory / Separate Part Type | Connecting cable |
| Accessory / separate part designation | Cable for 2-port adaptor |
| Accessory / separate part destination | Connection of XBT terminal to Mitsubishi Melsec PLC with XBTZGCOM1 adaptor |
Complementary
| Characteristic | Value(s) |
|---|---|
| Product Compatibility | XBTGK.... XBTGT4... XBTGT6... XBTGT2... XBTOT... XBTGT5... XBTGT7340 |
| Range Compatibility | Mitsubishi FX Mitsubishi QnA CPU Harmony HMI GTO Mitsubishi A CPU |
| Cable length | 16.4 ft (5 m) |
| Electrical connection | 1 connector SUB-D 9 Free end |
| Communication Port Protocol | QnA CPU (SIO) A CPU (SIO) FX (CPU) |
| Physical interface | RS422 |
Magelis XBT - serial link isolation unit with USB hub
plastic safety switch XCSTE - 1NC+1NO- slow break- 1entry tapped Pg 11 - 120 V
Schneider Electric is a global manufacturer of industrial automation and energy management solutions, including Modicon PLC platforms, EcoStruxure™ automation architecture, industrial HMIs, Altivar drives, motor control components, and power distribution systems. Schneider Electric technologies support scalable PLC-based machine control, process automation, and plant-wide energy integration across manufacturing, utilities, infrastructure, and industrial environments.
PLC Direct supplies Schneider PLC hardware, automation components, and industrial control parts supporting installed Schneider systems. Our Schneider collection serves customers sourcing replacement Modicon PLC modules, HMIs, drives, and Schneider Electric parts to maintain operational continuity within existing automation environments.
Why Choose Schneider Electric: Integrated PLC Control and Energy Management
Schneider Electric combines PLC control platforms, industrial communication, motor control, and energy management within unified automation architectures. Through Modicon PLC systems and EcoStruxure™ architecture, Schneider integrates machine-level control with plant-wide monitoring and operational visibility.
Schneider Electric PLC and automation systems are commonly deployed in:
- Manufacturing automation and machine control
- Water and wastewater treatment facilities
- Food and beverage production lines
- Oil and gas operations
- Power generation and energy distribution
- Packaging and material handling systems
- Infrastructure and building automation
- Process industries requiring integrated control and energy oversight
This broad deployment reflects Schneider Electric’s specialization in scalable PLC platforms, industrial networking, and energy-aware automation environments.
Schneider Electric Products and Solutions
Schneider Electric organizes its automation portfolio around PLC platforms, visualization systems, drive technologies, industrial communication infrastructure, motor control hardware, and energy management devices. The Schneider collection at PLC Direct focuses on hardware supporting Schneider systems in place for maintenance, replacement, and lifecycle continuity.
Schneider Electric Product Families
Schneider Electric’s automation portfolio includes:
- Modicon PLC Platforms: Modicon M221, M241, M251, M340, M580, and Quantum PLC systems designed for machine automation and process control. These platforms support Ethernet-based communication, distributed I/O architectures, and scalable system configurations.
- EcoStruxure™ Automation Architecture: An integrated framework combining PLC control, industrial networking, SCADA connectivity, and energy management within unified automation environments.
- HMI and Visualization Systems: Magelis and Harmony operator panels designed for machine-level monitoring and operator interaction within Schneider PLC systems.
- Variable Speed Drives and Motion Control: Altivar variable frequency drives (VFDs), servo drives, and motion control hardware supporting motor regulation and synchronized machine applications.
- Motor Control and Electrical Components: Contactors, motor starters, relays, and circuit protection devices supporting automation and power distribution systems.
- Industrial Communication and Networking: Communication modules and networking hardware supporting Modbus TCP/IP, EtherNet/IP, and other industrial protocols (model-dependent).
- Power Monitoring and Energy Management Devices: Power meters, protection relays, and monitoring systems integrated within industrial control environments.
Schneider Electric Products Available on PLC Direct
Schneider Electric products available through PLC Direct's collection include:
- Modicon PLC controllers and expansion modules
- Industrial HMI panels and operator interfaces
- Altivar drives and motion control hardware
- Communication modules and networking components
- Motor control and electrical control devices
- Replacement Schneider Electric PLC-integrated modules for installed systems
These products are sourced for repair, replacement, and lifecycle support of existing Schneider Electric automation systems.
Lifecycle Support for Schneider Electric Automation Systems
PLC Direct supports Schneider Electric automation systems by supplying inventory-backed hardware across multiple stages of the system lifecycle. Our focus centers on helping customers maintain operational continuity within installed Modicon PLC, Altivar drive, and Schneider industrial control environments. PLC Direct operates as an independent Schneider supplier supporting installed automation systems.
Lifecycle-focused support includes:
- Schneider Electric inventory supporting deployed PLC platforms
- Replacement Schneider PLC hardware for installed systems
- Availability of select legacy and discontinued Schneider Electric parts
- Drive systems and motor control components supporting ongoing operations\
- Communication modules supporting established PLC architectures
Additional support may include:
- Stock-backed availability for replacement needs
- Assistance in locating difficult-to-source legacy Schneider products
- Support with part number identification and compatibility verification
- 1-year warranty coverage on supplied products
PLC Direct supplies Schneider Electric automation hardware for replacement and maintenance purposes and does not provide system design, programming, or integration services.
Frequently Asked Questions
1. What types of Schneider Electric parts does PLC Direct carry?
PLC Direct carries Schneider Electric parts, including Modicon PLC controllers, HMI panels, Altivar drives, communication modules, and motor control components used within installed automation systems.
2. Is PLC Direct an authorized Schneider distributor?
PLC Direct is an independent Schneider supplier of automation components. We provide surplus sealed and refurbished Schneider Electric hardware backed by our 1-year warranty to support maintenance and lifecycle requirements.
3. Does PLC Direct provide technical support for Schneider PLC systems?
PLC Direct is a hardware supplier and does not provide programming, configuration, troubleshooting, or system integration services. We can assist with part number identification and compatibility verification.
4. What is a Schneider Electric PLC?
A Schneider Electric PLC is a programmable logic controller within the Modicon platform used for machine automation, process control, and industrial system management.
5. Where can I find replacement Schneider PLC modules and parts?
PLC Direct specializes in sourcing replacement Schneider Electric PLC modules and automation hardware supporting installed industrial systems, including select discontinued products.
