BSH1404P02F2P Schneider
Schneider BSH1404P02F2P Schneider
$6,980.06
Only 1 unit left

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Untapped
IP Degree of Protection IP50 standard
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake With
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
Feedback type Multiturn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P11A1P Schneider
Schneider BSH1404P11A1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP50 standard
Speed feedback resolution 131072 points/turn
Holding brake Without
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Single turn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P11A2P Schneider
Schneider BSH1404P11A2P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - keyed shaft - without brake - IP50
BSH1404P11F1P Schneider
Schneider BSH1404P11F1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP50 standard
Speed feedback resolution 131072 points/turn
Holding brake With
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Single turn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P11F2P Schneider
Schneider BSH1404P11F2P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP50 standard
Speed feedback resolution 131072 points/turn
Holding brake With
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Single turn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P12A1P Schneider
Schneider BSH1404P12A1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP50 standard
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake Without
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Multiturn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 10
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 3.9 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Coefficient 1_1 -0.00576666666666 N.m/rpm
Coefficient 1_2 -0.000000000000000019464694685851 N.m/rpm²
Coefficient 1_3 0.000000000000000000021479766618 N.m/rpm3
Coefficient 1_4 -0.000000000000000000000010776504 N.m/rpm4
Coefficient 1_5 0.000000000000000000000000002487 N.m/rpm5
Coefficient 1_6 0 N.m/rpm6
Saturation coefficient 1 0.00000000000000000127958882662
Saturation coefficient 2 -0.00554648987912541
Saturation coefficient 3 -0.000000000000000000071887012731
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
Motor voltage drop coefficient 1
BSH1404P12A2P Schneider
Schneider BSH1404P12A2P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP50 standard
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake Without
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Multiturn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P12F1P Schneider
Schneider BSH1404P12F1P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - keyed shaft - with brake - IP50
BSH1404P12F2P Schneider
Schneider BSH1404P12F2P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - keyed shaft - with brake - IP50
BSH1404P21A1P Schneider
Schneider BSH1404P21A1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Untapped
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn
Holding brake Without
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
Feedback type Single turn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P21A2P Schneider
Schneider BSH1404P21A2P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - untapped shaft - without brake - IP65
BSH1404P21F1P Schneider
Schneider BSH1404P21F1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Untapped
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn
Holding brake With
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
Feedback type Single turn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P21F2P Schneider
Schneider BSH1404P21F2P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Untapped
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn
Holding brake With
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
Feedback type Single turn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P22A1P Schneider
Schneider BSH1404P22A1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Untapped
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake Without
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
Feedback type Multiturn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P22F1P Schneider
Schneider BSH1404P22F1P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - untapped shaft - with brake - IP65
BSH1404P22F2P Schneider
Schneider BSH1404P22F2P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Untapped
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake With
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
Feedback type Multiturn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P31A1P Schneider
Schneider BSH1404P31A1P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - keyed shaft - without brake - IP65
BSH1404P31A2P Schneider
Schneider BSH1404P31A2P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn
Holding brake Without
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Single turn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P31F1P Schneider
Schneider BSH1404P31F1P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - keyed shaft - with brake - IP65
BSH1404P31F2P Schneider
Schneider BSH1404P31F2P Schneider
$0.00
Sold Out

AC servo motor BSH - 32.1 N.m - 3000 rpm - keyed shaft - with brake - IP65
BSH1404P32A1P Schneider
Schneider BSH1404P32A1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake Without
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Multiturn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P32A2P Schneider
Schneider BSH1404P32A2P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake Without
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 32
Lexium 05
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Multiturn SinCos Hiperface
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 23.7 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
type of cooling Natural convection
Length 15.06 in (382.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 57.3 lb(US) (26 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P32F1P Schneider
Schneider BSH1404P32F1P Schneider
$0.00
Sold Out

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake With
Mounting Support International standard flange
Electrical Connection Straight connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Multiturn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)
BSH1404P32F2P Schneider
Schneider BSH1404P32F2P Schneider
$5,120.79
Only 1 unit left

Main

Characteristic Value(s)
Device short name BSH
Product or Component Type Servo motor
Maximum mechanical speed 4000 rpm
Continuous stall torque 295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 400 V, three phase
295.6 lbf.in (33.4 N.m) LXM32.D72N4 24 A, 480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05AD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05BD57N4, 380...480 V, three phase
284.1 lbf.in (32.1 N.m) LXM05CD57N4, 380...480 V, three phase
Peak stall torque 916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 400 V, three phase
916.9 lbf.in (103.6 N.m) LXM32.D72N4 24 A, 480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05AD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05BD57N4, 380...480 V, three phase
558.39 lbf.in (63.09 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal output power 5000 W LXM32.D72N4 24 A, 400 V, three phase
5000 W LXM32.D72N4 24 A, 480 V, three phase
3400 W LXM05AD57N4, 380...480 V, three phase
3400 W LXM05BD57N4, 380...480 V, three phase
3400 W LXM05CD57N4, 380...480 V, three phase
Nominal torque 168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 400 V, three phase
168.2 lbf.in (19 N.m) LXM32.D72N4 24 A, 480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05AD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05BD57N4, 380...480 V, three phase
95.6 lbf.in (10.8 N.m) LXM05CD57N4, 380...480 V, three phase
Nominal speed 2500 rpm LXM32.D72N4 24 A, 400 V, three phase
2500 rpm LXM32.D72N4 24 A, 480 V, three phase
3000 rpm LXM05AD57N4, 380...480 V, three phase
3000 rpm LXM05BD57N4, 380...480 V, three phase
3000 rpm LXM05CD57N4, 380...480 V, three phase
Product compatibility LXM05AD57N4 380...480 V three phase
LXM05BD57N4 380...480 V three phase
LXM05CD57N4 380...480 V three phase
LXM32.D72N4 400 V three phase
LXM32.D72N4 480 V three phase
Shaft end Keyed
IP Degree of Protection IP65 standard
IP67 with IP67 kit
Speed feedback resolution 131072 points/turn x 4096 turns
Holding brake With
Mounting Support International standard flange
Electrical Connection Rotatable right-angled connectors

Complementary

Characteristic Value(s)
Range Compatibility Lexium 05
Lexium 32
supply voltage max 480 V
Phase Three phase
Continuous stall current 21.3 A
maximum continuous power 4.33 W
Maximum current Irms 72 A LXM32.D72N4
95.6 A LXM05AD57N4
95.6 A LXM05BD57N4
95.6 A LXM05CD57N4
Maximum permanent current 95.6 A
Switching frequency 8 kHz
Second shaft Without second shaft end
Shaft diameter 0.9 in (24 mm)
Shaft length 2.0 in (50 mm)
key width 1.6 in (40 mm)
Feedback type Multiturn SinCos Hiperface
Holding torque 318.6 lbf.in (36 N.m) holding brake
Motor flange size 5.5 in (140 mm)
Number of motor stacks 4
Torque constant 1.57 N.m/A 248 °F (120 °C)
Back emf constant 104 V/krpm 248 °F (120 °C)
Number of motor poles 5.0
Rotor inertia 29.2 kg.cm²
Stator resistance 0.28 Ohm 68 °F (20 °C)
Stator inductance 2.035 mH 68 °F (20 °C)
Stator electrical time constant 13.93 ms 68 °F (20 °C)
Maximum radial force Fr 1840 N 3000 rpm
2110 N 2000 rpm
2660 N 1000 rpm
Maximum axial force Fa 0.2 x Fr
Brake pull-in power 26 W
type of cooling Natural convection
Length 16.6 in (420.5 mm)
Centring collar diameter 5.1 in (130 mm)
centring collar depth 0.1 in (3.5 mm)
Number of mounting holes 4
Mounting holes diameter 0.4 in (11 mm)
Circle diameter of the mounting holes 6.5 in (165 mm)
Product Weight 61.3 lb(US) (27.8 kg)
Sizing reference BSH1404P
Network number of phases 3
Accuracy error [angular] 1.4 °
Temperature copper hot 248 °F (120 °C)
Temperature magnet hot 212 °F (100 °C)
Temperature magnet rt 68 °F (20 °C)

Recently viewed
