This complete push-button provides an ergonomic interface for controlling your marchine. It is easily installed and into a standard 22mm diameter panel cut-outs and connected to control circuits with classic screw-clamp connections. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration, high pressure washer and dust resistant thanks to its IP65 protection, making it ideal for operation in harsh environments.
Main
| Characteristic | Value(s) |
|---|---|
| Range of product | Easy Harmony XB2 |
| Product or component type | Complete push-button |
| Device presentation | Complete product |
| Device short name | XB2 |
| Bezel material | Chromium plated metal |
| Mounting diameter | 22.5 mm |
| Sale per indivisible quantity | 1 |
| Head type | Standard |
Complementary
| Characteristic | Value(s) |
|---|---|
| Fixing collar material | Zamak |
| Terminals description ISO n°1 | (13-14)NO |
| Overvoltage category | Class I conforming to IEC 60536 |
| Operating position | Any position |
| Cap/operator or lens colour | Green |
| Product compatibility | ZB2..C |
| Device mounting | Fixing hole - diameter: 22.5 mm |
| Fixing center | >= 30 x 40 mm (1...6 mm thick panel) zamak - thickness: 1â¦6 mm |
| Fixing mode | Fixing screw beneath head recommended torque: 0.8 N.m Fixing screw beneath head recommended torque: 1.0 N.m |
| Marking | Unmarked |
| Shape of signaling unit head | Round |
| Type of operator | spring return |
| Operator profile | Green flush, unmarked |
| Contacts type and composition | 1 NO |
| Contact operation | Slow-break |
| Contacts usage | Standard contacts |
| Positive opening | Without |
| Operating travel | 2.88 mm (NO changing electrical state) 5.0 mm (total travel) |
| Mechanical durability | 3000000 cycles |
| Connections - terminals | Screw clamp terminal, <= 2 x 1.5 mm² with and without cable ends Screw clamp terminal, <= 1 x 2.5 mm² with and without cable ends Screw clamp terminal, >= 1 x 0.5 mm² with and without cable ends Faston terminals, connection size: 6.3 mm |
| Tightening torque | 0.8â¦1.0 N.m |
| Shape of screw head | Cross compatible with Philips no 1 screwdriver Cross compatible with pozidriv No 1 screwdriver Slotted compatible with flat à 4 mm screwdriver Slotted compatible with flat à 5.5 mm screwdriver |
| Contacts material | Silver alloy (Ag/Ni) |
| Short-circuit protection | 10 A gL fuse type gG conforming to IEC 60947-5-1 |
| [Ith] conventional free air thermal current | 10 A conforming to IEC 60947-5-1 |
| [Ui] rated insulation voltage | 600 V (pollution degree 3) conforming to IEC 60947-1 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-1 |
| [Ie] rated operational current | 3 A at 240 V, AC-15, A600 conforming to IEC 60947-5-4 0.27 A at 250 V, DC-13, Q600 conforming to IEC 60947-5-4 |
| Electrical durability | 1000000 cycles, AC-15, 3 A at 240 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C 1000000 cycles, DC-13, 0.27 A at 250 V, operating rate <3600 cyc/h, load factor: 0.5 conforming to IEC 60947-5-1 appendix C |
| Electrical reliability | Î < 10exp(-6) at 5 V, 1 mA in clean environment conforming to IEC 60947-5-4 Î < 10exp(-8) at 17 V, 5 mA in clean environment conforming to IEC 60947-5-4 |
| Height | 30 mm |
| Width | 40 mm |
| Depth | 54.5 mm |
| Product weight | 0.07 kg |
| Customizable | No |
| Type of operator | Spring return |
Harmony 22 mm modular push buttons, selector switches, pilot lights are designed for industry. This range combines simplicity of setup, flexibility and a robust construction. An ingenious locking system consisting of a snap fit head and body that can be tightened with a single screw but still ensuring an easy and yet secure mounting. Harmony XB4/ZB4 are 22 mm chromium plated metal modular push buttons, selector switches and pilot lights connecting to fully metal mounting collar. The operators can be purchased as complete operators or various modules that can be assembled to meet the userâs specific requirement. Harmony XB5/ZB5 are 22 mm plastic modular push buttons, selector switches, pilot lights. The operator can have a round and square plastic bezel. The contacts can be used for low load electrical contact and high power applications. Shake proof connection screws make periodic retightening unnecessary. A complete set of accessories to provide a solution for applications where exposure to high pressure cleaning, dust and extreme temperatures is an everyday occurrence. These harmony 22mm push buttons are used by machine manufacturers (automotive, textiles, timber) and control system panel builders. Certified and approved for meeting requirements throughout all continents: EN/IEC, UL, NEMA, CSA, CCC, Gost, JIS and many more. They have UL and CE markings and have ratings up to IP66 and IP69K.
Main
| Characteristic | Value(s) |
|---|---|
| Range of Product | Harmony XAC |
| Product or Component Type | Head for push-button |
| Component name | XACA |
Complementary
| Characteristic | Value(s) |
|---|---|
| Marking | Unmarked |
| Operator additional information | Booted |
| Cap/operator or lens colour | Green |
| Product Compatibility | XACA.. |
| Mounting Location | Front of enclosure |
| Sale per indivisible quantity | 10 |
| Standards | IEC 60947-5-1 CSA C22.2 No 14 UL 508 IEC 60204-32 |
| Ambient air temperature for operation | -13â¦158 °F (-25â¦70 °C) |
| Ambient Air Temperature for Storage | -40â¦158 °F (-40â¦70 °C) |
| Vibration resistance | 15 gn (f= 10â¦500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 100 gn IEC 60068-2-27 |
| Overvoltage category | Class II conforming to IEC 61140 |
| IP degree of protection | IP65 conforming to IEC 60529 |
| IK degree of protection | IK08 conforming to IEC 62262 |
| Product Weight | 0.02 lb(US) (0.01 kg) |
