The Turck TNLR-Q80-H1147 is a high-frequency RFID read/write head designed for industrial identification applications. Operating at 13.56 MHz, this transceiver head enables contactless data communication with compatible RFID transponders in automated manufacturing and logistics environments. The device features a rectangular housing with an active sensing face on top and is constructed from PBT-GF30-V0 plastic for durability. It is designed exclusively for use with BL ident interface modules in bus line topology configurations with TBEN-series controllers. The non-flush mountable design offers a maximum read/write distance of 215 mm, making it suitable for applications requiring reliable identification of pallets, carriers, and workpieces in assembly lines, material handling systems, and process tracking applications.
Item Details
- Brand Name: Turck
- Manufacturer: Hans Turck GmbH & Co. KG
- Item Type Name: HF RFID Read/Write Head
- Product Family / Series: BL ident RFID System
- Model Number: 7030230
- Part Number Variants: TNLRQ80H1147, TNLR-Q80-H1147
Product Specifications
- operating_voltage: 19.2 to 28.8 V DC
- operating_frequency: 13.56 MHz
- rated_operational_current: 90 mA
- max_read_write_distance: 215 mm
- mounting_type: Non-flush
- connection_type: M12 x 1 connector, 1-pin
- housing_material: PBT-GF30-V0 plastic
- ambient_temperature_range: -25 to +70 °C
- protection_rating: IP67
Additional Details
- Country of Origin*: Germany
- Lifecycle Status: Commercialized
- Ean Code: 4047101115222
- Special Requirements: Powered and operated only via BL ident interface module; must be used in line topology with TBEN-S*-2RFID-* or TBEN-L*-4RFID-*; max 32 nodes per line
*Country of origin may vary.
Measurements
- Dimensions: 92 x 80 x 40 mm (W x H x D)
- Housing Height: 40 mm
