The Keyence SR-X300 is an advanced AI-powered industrial code reader designed for high-speed, accurate reading of 1D barcodes and 2D codes in manufacturing, logistics, and inspection applications. Featuring a 2.3-megapixel CMOS image sensor with 1920 × 1200 pixel resolution, the device integrates an ultra-compact imaging lens, high-intensity red/white LED illumination, and autofocus capability. An inference-specific AI chip, trained on over 100,000 images, enables superior performance on difficult-to-read codes including damaged, stained, or low-contrast markings. The reader supports extensive code symbologies including QR, DataMatrix, PDF417, CODE128, and many others. With IP65/IP67 enclosure rating and multiple communication interfaces including Ethernet (TCP/IP, EtherNet/IP, PROFINET, OPC UA), RS-232C serial, and USB 2.0, the SR-X300 integrates seamlessly into automated production lines and Industry 4.0 environments.
Item Details
- Brand Name: Keyence
- Manufacturer: Keyence Corporation
- Item Type Name: AI-Powered Barcode/Code Reader
- Product Family / Series: SR-X Series
- Model: SR-X300
- Type: Standard type (2.3 megapixels)
Product Specifications
- sensor_type: CMOS image sensor
- resolution: 1920 × 1200 pixels (2.3 megapixels)
- focus: Auto
- illumination_source: High-intensity red/white LED
- pointer_source: High-intensity green LED
- minimum_resolution_2D: 0.024 mm
- minimum_resolution_barcode: 0.082 mm
- reading_distance: 70 to 1000 mm
- field_of_view: 104 × 65 mm at 300 mm distance
- supported_2D_codes: QR, MicroQR, DataMatrix (ECC200), DMRE, GS1 DataMatrix, PDF417, MicroPDF417, GS1 Composite (CC-A/CC-B/CC-C), DotCode, MaxiCode, Aztec Code
- supported_barcodes: CODE39, ITF, 2of5 (Industrial 2of5), COOP 2of5, NW-7 (Codabar), CODE128, GS1-128, GS1 DataBar, CODE93, JAN/EAN/UPC, Trioptic CODE39, CODE39 Full ASCII, Pharmacode, Postal (Japan Postal, IMB)
- ethernet_protocols: TCP/IP, SNTP, FTP, SFTP, HTTP, HTTPS, BOOTP, EtherNet/IP, PROFINET, KV STUDIO, MC protocol, OMRON PLC link
- serial_communication: RS-232C-compliant, 600 to 115200 bps
- serial_protocols: No-protocol, KV STUDIO, MC protocol, SYSWAY
- usb_standard: USB 2.0 High Speed compliant
- power_voltage: 24 V DC +25%/-20%
- current_consumption: Approx. 750 mA
- enclosure_rating: IP65/IP67 (IEC60529)
- operating_temperature: 0 to +45°C
- relative_humidity: 35 to 85% RH (No condensation)
- storage_temperature: -10 to +50°C
- storage_humidity: 35 to 85% RH (No condensation)
Additional Details
- Ai Capabilities: Inference-specific AI chip trained on over 100,000 images for improved code reading performance
- Led Safety Classification: IEC 62471 (JIS C 7550) Risk Group 1 (low risk)
Measurements
- Weight: 200 g
