The Keyence SR-2000 is a high-performance 1D/2D code reader designed for industrial automation applications requiring barcode and 2D code scanning over extended distances. It features a CMOS image sensor with 2048 x 1536 pixel resolution and autofocus capability. The reader achieves reading distances from 100 mm to 2000 mm with a field of view of 263 x 197 mm at 800 mm distance, significantly exceeding conventional models. The SR-2000 supports multiple code types including QR, DataMatrix, PDF417, and various 1D barcodes. It is equipped with high intensity red LED illumination and a green LED pointer, with Ethernet and USB connectivity options. The device features 2 digital inputs and 3 outputs, operates on 24 VDC power supply, and carries IP65 environmental protection rating. Fully automatic calibration enables stable code reading on moving objects such as conveyor systems and robotic transfer applications without requiring expert setup or additional external lighting equipment.
Item Details
- Brand Name: Keyence
- Manufacturer: Keyence Corporation
- Item Type Name: 1D/2D Barcode Reader
- Product Family / Series: SR-2000 Series
Product Specifications
- sensor_type: CMOS Image Sensor
- sensor_resolution: 2048 x 1536 pixels
- reading_distance: 100 to 2000 mm
- field_of_view_at_800mm: 263 x 197 mm
- supported_2D_codes: QR, MicroQR, DataMatrix (ECC200), GS1 DataMatrix, PDF417, MicroPDF417, GS1 Composite (CC-A/CC-B/CC-C), DotCode
- supported_1D_codes: CODE39, ITF, 2of5, COOP 2of5, NW-7 (Codabar), CODE128, GS1-128, GS1 DataBar, CODE93, JAN/EAN/UPC, Trioptic CODE39, CODE39 Full ASCII, Pharmacode, Postal
- illumination: High Intensity Red LED
- pointer: High Intensity Green LED
- autofocus: Yes
- connectivity: Ethernet, USB
- digital_inputs: 2
- digital_outputs: 3
- power_supply: 15 to 26.4 V DC
- environmental_protection: IP65
Additional Details
- Certifications / Approvals: UL, CSA
Measurements
- Weight: 0.3 kg
