The Control Techniques SKC3400220 is an AC variable frequency drive from the Commander SK series, designed for precise control of three-phase induction motors in industrial automation applications. This drive provides 2.2 kW (3 HP) power output with a continuous output current rating of 5.1 A and operates on three-phase 380-480 VAC input voltage. The Commander SK series is engineered for simplicity, compactness, and reliability, offering both sensorless vector control and V/Hz modes for flexible motor control. It features a user-friendly keypad interface for straightforward commissioning and parameter adjustment, integrated EMC filter compliant with EN 61800-3 standards, and Modbus RTU RS485 serial communications as standard. The drive incorporates advanced microprocessor technology with DSP control and IGBT inverter section, ensuring efficient PWM control with adjustable carrier frequency. Suitable for manufacturing, processing, and automation applications requiring reliable speed, torque, and position control.
Item Details
- Brand Name: Control Techniques
- Manufacturer: Nidec Control Techniques
- Item Type Name: AC Variable Frequency Drive
- Product Family / Series: Commander SK
Product Specifications
- power_rating: 2.2 kW
- horsepower_rating: 3 HP
- input_voltage: 380-480 V AC, three-phase
- input_current: 7.3 A
- output_current_continuous: 5.1 A
- output_current_overload: 7.7 A (60 seconds)
- control_modes: Sensorless vector mode, V/Hz mode
- communications: Modbus RTU RS485
- emc_compliance: EN 61800-3, integrated EMC filter
- enclosure_rating: IP20
- motor_power_range: 0.25 kW to 4 kW (0.33 HP to 5 HP)
- motor_type: Three-phase AC induction motors
- switching_frequency: Adjustable carrier frequency PWM
Additional Details
- Certifications / Approvals: EN 61800-3
- Technology: DSP digital signal processor, IGBT inverter, surface mount technology
