The Honeywell RM7895B1013 is a microprocessor-based integrated primary burner control relay module designed for automatically fired gas, oil, coal, or combination fuel single-burner applications. Part of the 7800 Series, it provides on-off primary control functionality with programmable pre-ignition purge timing. The module features dynamic airflow checking, selectable interlocks, intermittent pilot operation, and flashing main flame establishment period. It includes five LEDs for sequence status indication and supports system diagnostics and troubleshooting. The control requires external components including a Q7800A or Q7800B universal wiring subbase, a compatible flame amplifier from the 7800 series, and an ST7800A prepurge timer card for full operation. Optional accessories include keyboard display module, PC interface, remote display module, and DATA CONTROLBUS MODULE for enhanced system integration and monitoring.
Item Details
- Brand Name: Honeywell
- Manufacturer: Honeywell International Inc.
- Item Type Name: Burner Control Relay Module
- Product Family / Series: 7800 Series Relay Modules
- Model Number: RM7895B1013
- Replaces: R4795EF
- Pilot Type: Intermittent
- Control Type: On-Off Primary Control with Prepurge
Product Specifications
- voltage: 120 V AC (+10%, -15%)
- frequency: 50 Hz / 60 Hz (±10%)
- pilot_flame_establishing_period: 4 sec or 10 sec
- main_flame_establishing_period: Intermittent (Flashing)
- airflow_check: Dynamic
- interlocks: Selectable (Lockout and Running)
- prepurge_timing: Determined by ST7800A Purge Timer Card
- flame_amplifier: 7800 Series Amplifiers (Interchangeable plug-in)
- sequence_indicators: 5 LEDs
Additional Details
- Country of Origin*: Mexico
- Certifications / Approvals: UL Component Recognized (File No. MP268, Guide No. MCCZ), CSA Certified (File No. LR95329-3), FCC Part 15 Class B Emissions
- Required Components: Q7800A or Q7800B Universal Wiring Subbase, 7800 Series Flame Amplifier, ST7800A Purge Timer Card
- Optional Components: Keyboard Display Module, PC Interface, DATA CONTROLBUS MODULE, Remote Display Module, First-Out Expanded Annunciator, Combustion System Manager Software
- Mounting: Q7800A & Q7800B Subbases
- Upc: 085267082730
*Country of origin may vary.
Measurements
- Weight: 0.9 kg (1 lb 15 oz)
- Dimensions: 127 mm wide x 127 mm high x 133 mm deep (with Q7800A Subbase) or 155 mm deep (with Q7800B Subbase)
- Shipping Storage Temperature Range: -40°C to +60°C
