The RLK28-8-H-2000-IR-Z/31/116 is a background suppression photoelectric sensor from Pepperl+Fuchs designed for precision object detection in industrial automation applications. This sensor features an infrared LED transmitter operating at 880 nm wavelength, providing minimal black-white difference for reliable detection of various object colors and surfaces. The device incorporates adjustable background suppression technology with a detection range from 20 mm to 2000 mm, ensuring accurate target detection while ignoring objects beyond the set range. It includes programmable timing functions including ON delay, OFF delay, one-shot, and combination modes adjustable from 0.1 to 10 seconds. The sensor operates on universal voltage supply of 12 to 240 V AC/DC and features a relay output with SPDT configuration. The rectangular ABS plastic housing includes DIP switches for configuration, LED status indicators, and spring contact terminals for easy installation.
Item Details
- Brand Name: Pepperl+Fuchs
- Manufacturer: Pepperl+Fuchs SE
- Item Type Name: Background Suppression Photoelectric Sensor
- Product Family / Series: RLK28 Series
- Part Number: RLK28-8-H-2000-IR-Z/31/116
- Alternate Part Number: 134133
- Sensor Type: Background suppression sensor with terminal compartment
Product Specifications
- detection_range_min: 20 mm
- detection_range_max: 2000 mm
- adjustment_range: 200 mm to 2000 mm
- light_source: Infrared LED (IRED)
- wavelength: 880 nm
- supply_voltage: 12 to 240 V AC/DC
- output_type: Relay SPDT
- switching_voltage_max: 250 V AC/DC
- switching_power_dc_max: 50 W
- switching_power_ac_max: 500 VA
- response_time: 20 ms
- timer_functions: ON delay (GAN), OFF delay (GAB), one shot (IAB), ON delay-one shot (GAN-IAB), adjustable 0.1 to 10 s
- operating_temperature: -40°C to 60°C
- connection_type: Spring contacts (QC tabs)
- indicator: LED status display
Additional Details
- Country of Origin*: VN
- Body Material: ABS Plastic
- Body Style: Rectangular
- Ul Approval: E87056, cULus Listed
- Rohs Compliant: Yes
*Country of origin may vary.
Measurements
- Dimensions: 54.3 L x 25.8 W x 88 D mm
