| Characteristic | Value(s) |
|---|---|
| Control circuit voltage limits | 20...28 V for DC circuit 24 V in operation 14.5 V for DC circuit 24 V drop-out |
| Typical current consumption | 130 mA at 24 V DC I maximum while closing 60 mA at 24 V DC I rms sealed |
| Heat dissipation | 2 W for control circuit |
| Operating time | 35 ms opening for control circuit 70 ms closing for control circuit |
| Reset | Manual reset |
| Standards | EN 60947-6-2 IEC 60947-6-2 UL 508 CSA C22.2 No 14 |
| Product certifications | UL CSA |
| [Ui] rated insulation voltage | 250 V conforming to IEC 60947-6-2 250 V conforming to UL 60947-4-1 250 V conforming to CSA C22.2 No 60947-4-1 |
| [Uimp] rated impulse withstand voltage | 4 kV conforming to IEC 60947-6-2 |
| Fixing mode | Plug-in (front face) |
| Width | 45 mm |
| Height | 66 mm |
| Depth | 60 mm |
| Compatibility code | LUCB |
