The Mitsubishi HF-KN23K is a compact AC brushless rotary servo motor from the MELSERVO JN series, designed for precision motion control in industrial automation applications. This low-inertia motor features a keyed shaft configuration and incorporates an incremental feedback encoder with 131,072 pulses per revolution, equivalent to 17-bit resolution. Operating on 200 VAC class power supply, it delivers 200 W rated output with a rated torque of 0.64 Nm and rated speed of 3000 rpm. The motor utilizes natural cooling and features a totally enclosed design with IP65 protection, making it suitable for demanding industrial environments. It is commonly deployed in robotics, machine tools, packaging equipment, and automated material handling systems where precise positioning and reliable performance are essential.
Item Details
- Brand Name: Mitsubishi
- Manufacturer: Mitsubishi Electric
- Item Type Name: AC Brushless Servo Motor
- Product Family / Series: MELSERVO JN series
- Series: HF-KN series
- Shaft Type: Keyed shaft
- Brake: No electromagnetic brake
- Cooling Method: Natural cooling
Product Specifications
- rated_power_output: 200 W
- rated_torque: 0.64 Nm
- maximum_torque: 1.9 Nm
- rated_speed: 3000 rpm
- maximum_speed: 4500 rpm
- rated_current: 1.4 A
- maximum_current: 4.2 A
- supply_voltage: 200 V AC
- encoder_resolution: 131072 ppr (17-bit)
- encoder_type: Incremental feedback encoder
- rotor_inertia: 0.000024 to 0.000031 kg·m²
- flange_mounting: 60 x 60 mm
- protection_rating: IP65
Additional Details
- Motor Type: Low inertia / Small power capacity
- Operating Temperature: 0 to +40 °C
Measurements
- Weight: 1.0 to 1.4 kg
- Length Dimension L: 88.2 mm
- Length Dimension Kl: 40 mm
