The Honeywell C7061A1038 Purple Peeper is a dynamic self-checking ultraviolet flame detector designed for industrial burner management systems. It uses a solid-state UV sensor to detect ultraviolet radiation emitted by the combustion of gas, oil, and other carbon-containing fuels. The detector features an oscillating shutter that interrupts UV radiation 12 times per minute to provide continuous sensor tube integrity verification. It must be used with Honeywell R7861 Dynamic Self-Check Amplifiers and 7800 Series or compatible flame safeguard controls. The unit is housed in a violet cast-aluminum enclosure with a separate mounting flange incorporating a protective heat block. This model includes a Brad Harrison 41310 type connector for rapid electrical installation and is suitable for continuous operation in industrial combustion applications.
Item Details
- Brand Name: Honeywell
- Manufacturer: Honeywell International Inc.
- Item Type Name: Dynamic Self-Check Ultraviolet Flame Detector
- Product Family / Series: C7061A Series Purple Peeper
- Model Number: C7061A1038
Product Specifications
- voltage: 120 VAC or 120/230 VAC
- frequency: 50/60 Hz
- operating_temperature: -40°C to 80°C
- storage_temperature: -50°C to 80°C
- enclosure_rating: NEMA 4 / IP66
- mounting_thread: 3/4 inch NPT
- connector_type: Brad Harrison 41310 (5-pin)
- shutter_cycle_rate: 12 cycles per minute
- viewing_window_pressure_rating: 20 psi (138 kPa)
- uv_sensing_tube: 129464N (-40°C rated)
- compatible_amplifier: R7861 Dynamic Self-Check Amplifier
- fuel_types: Gas, oil, and other carbon-containing fuels
Additional Details
- Lifecycle Status: Discontinued (replaced by C7061A1046)
- Approvals: CE approved per EN 298, SIL3 capable
Measurements
- Weight: 1.2 kg (2.6 lbs)
- Dimensions: 11 x 9 x 6 inches (279 x 229 x 152 mm)
