The Turck BI40-CP80-FZ3X2 is a rectangular embeddable inductive proximity sensor with a 40 mm rated sensing distance. Designed with a CP80 housing format measuring 80 x 80 mm, this sensor features programmable normally open or normally closed output configurations. The device operates on both AC and DC power supplies, accepting 20-250 VAC or 10-300 VDC in a 2-wire configuration. Constructed with PBT-GF30-V0 plastic housing material, it is rated IP67 for protection against dust and water ingress. The sensor is suitable for flush mounting in metal environments and includes dual LED indicators for power and switching state visualization. Typical applications include position detection, object counting, and limit switching in industrial automation and manufacturing environments.
Item Details
- Brand Name: Turck
- Manufacturer: Turck Inc.
- Item Type Name: Inductive Proximity Sensor
- Product Family / Series: Rectangular Inductive Sensors
- Housing Type: CP80 Rectangular
- Mounting Type: Embeddable (Flush Mountable)
- Output Configuration: Programmable NO/NC
Product Specifications
- rated_sensing_distance: 40 mm
- mounting_condition: Flush (Embeddable)
- output_type: 2-Wire AC/DC
- operating_voltage_ac: 20-250 VAC
- operating_voltage_dc: 10-300 VDC
- ac_rated_current: ≤400 mA
- dc_rated_current: ≤300 mA
- switching_frequency: 0.02 kHz
- frequency: 50-60 Hz
- repeat_accuracy: ≤2% of full scale
- hysteresis: 3-15%
- correction_factors: St37=1; Al=0.3; Stainless Steel=0.7; Ms=0.4
- protection_class: IP67
- housing_material: Plastic PBT-GF30-V0
- active_area_material: PBT-GF30-V0
- indicator: 2 LED (Power-on: Green; Switching state: Red)
Additional Details
- Ambient Temperature: -25 to +70 °C
- Vibration Resistance: 55 Hz (1 mm)
- Shock Resistance: 30 g (11 ms)
- Isolation Test Voltage: 1.5 kV
- Wire Break Reverse Polarity Protection: Yes
- Mttf: 2283 years (acc. to SN 29500)
Measurements
- Weight: 0.58 lbs
- Dimensions: 80 x 80 x 41 mm
