| Characteristic | Value(s) |
|---|---|
| [Us] rated supply voltage | 230 V AC (+/- 20 %) |
| Network frequency | 50/60 Hz |
| Power consumption in VA | 3 VA |
| digital input number | 2 |
| Input type | Dry contact 230 V AC 2 mA |
| Voltage state 1 guaranteed | >= 164 V for digital input |
| Voltage state 0 guaranteed | <= 40 V for digital input |
| Current state 1 guaranteed | >= 2 mA (digital input) |
| Current state 0 guaranteed | <= 0.5 mA (digital input) |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| Local signalling | Green, orange and red LED for product status |
| Switching frequency | 10 Hz maximum |
| Colour | White (RAL 9003) |
| 9 mm pitches | 2 |
| Height | 85 mm |
| Material | PA6 GF30 |
| Width | 18 mm |
| Depth | 62 mm |
| Product weight | 75 g |
| Connections - terminals | Tunnel type terminals (top) - 1 cable(s) 1â¦16 mm² (AWG 18...AWG 16) - rigid Tunnel type terminals (top) - 1 cable(s) 0.5â¦10 mm² (AWG 21...AWG 8) - flexible Tunnel type terminals (bottom) - 1 cable(s) 1â¦6 mm² (AWG 18...AWG 10) - rigid Tunnel type terminals (bottom) - 1 cable(s) 0.5â¦4 mm² (AWG 21...AWG 12) - flexible Tunnel type terminals (bottom) - 1 cable(s) 0.5â¦4 mm² (AWG 21...AWG 12) - flexible with ferrule Tunnel type terminals (bottom) - 2 cable(s) 1.5â¦2.5 mm² (AWG 16...AWG 14) - rigid Tunnel type terminals (bottom) - 2 cable(s) 1.5â¦2.5 mm² (AWG 16...AWG 14) - flexible |
| Wire stripping length | 14 mm for top connection 9 mm for bottom connection |
| Tightening torque | Power supply: 2 N.m top Digital input: 1 N.m bottom |
| Standards | ETSI EN 300 328 ETSI EN 301 489-1 EN/IEC 61326-1 ETSI EN 301 489-17 EN/IEC 61010-1 EN/IEC 62479 EN/IEC 61010-2-201 |
