The Siemens 6SL3040-1LA01-0AA0 is a CU310-2 PN control unit designed for single-axis motor control applications within the SINAMICS S120 modular drive system. This compact control unit features an integrated PROFINET interface for high-speed industrial Ethernet communication, enabling seamless integration into distributed automation architectures. It controls power modules in blocksize format and supports connection of DRIVE-CLiQ motors or Sensor Modules Cabinet-Mounted via the integrated DRIVE-CLiQ socket. The unit provides precise closed-loop control for speed, torque, and position regulation of AC servo and vector motors. Shipped without a CompactFlash card, it offers robust operation with minimal failure points. The CU310-2 PN is suitable for demanding industrial applications including packaging machinery, printing systems, and precision machine tools where reliable motion control and real-time communication are essential.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: Drive Control Unit
- Product Family / Series: SINAMICS S120
- Model Designation: CU310-2 PN
- Communication Interface: PROFINET, EtherNet/IP
- Compact Flash Card: Not included
Product Specifications
- power_supply: 24 V DC
- power_consumption: 20 W
- digital_inputs: 11 (voltage range -3 to 30 V)
- digital_io_bidirectional: 8 (voltage -3 to 30 V, max output current 500 mA)
- analog_inputs: 1 (voltage range -10 to 10 V or -20 to 20 mA)
- digital_output_voltage: 24 V DC
- digital_output_current: 0.5 A
- encoder_interface: TTL/HTL or SSI
- operating_temperature: 0 to 55 °C
- storage_temperature: -25 to 55 °C
- transport_temperature: -40 to 70 °C
Additional Details
- Country of Origin*: Germany
- Ean: 4042948660119
*Country of origin may vary.
Measurements
- Weight: 0.95 kg
- Dimensions: 191 x 73 x 75 mm (H x W x D)
