The Siemens 6FX8002-5CN06-1DA0 is a pre-assembled power cable from the MOTION-CONNECT 800 PLUS series, designed for industrial motor drive applications. This cable facilitates the connection between SIMOTICS motors and SINAMICS S120 booksize motor modules. It features four conductors with a 1.5 mm² cross-section and PUR outer jacket providing durability in demanding industrial environments. The cable is equipped with an M23 SPEED-CONNECT connector and is fully shielded to ensure reliable power transmission. With its pre-assembled design, it simplifies installation and reduces setup time while maintaining superior quality and system reliability. The cable supports flexible and fixed installation applications with specified bending radii for different use cases.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens
- Item Type Name: Pre-assembled Power Cable
- Product Family / Series: MOTION-CONNECT 800 PLUS
Product Specifications
- voltage_rating: 600/1000 V AC
- conductor_count: 4
- conductor_cross_section: 1.5 mm²
- cable_length: 30 m
- cable_outer_diameter: 9.5 mm
- insulation_material: CFC
- cable_jacket_material: PUR
- cable_color: Orange
- shielding: Complete shield
- connector_type_motor_side: M23 SPEED-CONNECT
- connector_type_drive_side: SINAMICS S120 Booksize Motor Module C/D
- operating_temperature: -50 to 80 °C
Additional Details
- Compatible Systems: SINAMICS S120, SIMOTICS M-1PH8 motors
- Cable Type: Basic power cable
