ABB New Stock Image

1SDA101366R1 ABB

ABB EcoSolutions

ABB EcoSolutions:
Yes
ABB Site Meeting Group Waste To Landfill Target:
UL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions:
Recyclability Rate of the Product acc. to EN45555:
Design for Closing Resource Loops - Standard EN45555 - 64.1 %

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
b9104628-c701-4da2-884e-ef4788561080 Italy
Simplified SCIP:
b3c498db-8293-4260-85ee-8ac32aaf2464 Germany
2b1dec6f-dcbf-41b3-8bc8-cc507db6658b Germany
8d9267db-2bad-4c8d-8ed8-8316a60a0803 Denmark
f4b1bc98-e4e2-4eb4-983b-fae6f40993c9 Germany
a58eb7c8-3ab5-4e60-b666-ca4fb0ff840a Croatia
fb7ee77e-46d9-4979-9d01-b3e1531e748a Czech Republic
14f4a852-958f-444a-b029-c914247a6030 Poland
4357a338-89e9-43e5-8baf-5deb48315089 Netherlands
1a930690-1e0e-40eb-8935-2f105d139469 Netherlands
bc131467-79ce-455b-8b0b-bec83fbda032 Estonia
5a975bb7-0501-452b-b7c0-a3196637d486 Greece
01449d32-838d-4ec4-9335-a2a4fcb5e4a8 Portugal
5c235cae-95fb-45ae-9ae8-bb0c55afb61b Bulgaria
1e96e278-ea5c-4d46-acc1-1ef88cc5d930 Sweden
e8338b5a-db3c-49c1-8dd4-812c65bb0a9d Poland
a7882aec-a304-452b-8580-21f4e9a3051e France
d226bad3-fb9e-49be-b497-1e044f820f85 Sweden
8b002a7b-ad1e-44e8-bf65-0c96908551a3 Germany
a848257d-8646-4daa-986a-e1a228f3b1d5 Germany
e8334f4e-17e2-4608-a5ad-30edef4926c2 France
65aa9ef3-75c8-4c33-a219-b20f15e058fd Netherlands
4a7c9f30-7364-40f6-918f-a6d5db76a1ec Spain
282c2b4f-e8f1-4063-b34e-982f7f8f6849 Netherlands
024f8714-7781-4b7e-a81b-9ff902aee4a9 Poland
264f799f-4c2b-45a4-87ba-d3ef6765de61 Norway
9ad54592-28c0-4987-8084-4b40d2dbf941 Finland
d0c199d0-ba73-42a9-9246-1a9cf10042dd Netherlands
b3c498db-8293-4260-85ee-8ac32aaf2464 Germany
2b1dec6f-dcbf-41b3-8bc8-cc507db6658b Germany
8d9267db-2bad-4c8d-8ed8-8316a60a0803 Denmark
f4b1bc98-e4e2-4eb4-983b-fae6f40993c9 Germany
a58eb7c8-3ab5-4e60-b666-ca4fb0ff840a Croatia
fb7ee77e-46d9-4979-9d01-b3e1531e748a Czech Republic
14f4a852-958f-444a-b029-c914247a6030 Poland
4357a338-89e9-43e5-8baf-5deb48315089 Netherlands
1a930690-1e0e-40eb-8935-2f105d139469 Netherlands
bc131467-79ce-455b-8b0b-bec83fbda032 Estonia

Environmental

Ambient Air Temperature:
Operation -40 ... 125 °C
Environmental Information:

Ordering

Order Code US and Canada:
XSECAFAZZAAAA00000
E-Number (Norway):
4380711
EAN:
8056221011846
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85362090

Dimensions

Product Net Width:
210 mm
Product Net Height:
268 mm
Product Net Depth / Length:
178 mm
Product Net Weight:
11 kg

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
280 mm
Package Level 1 Height:
350 mm
Package Level 1 Depth / Length:
360 mm
Package Level 1 Gross Weight:
12.5 kg
Package Level 1 EAN:
8056221011846

Additional Information

Circuit Breaker Type to be Associated:
Power Distribution
Product Main Type:
SACE Tmax XT
Product Name:
Moulded Case Circuit Breaker
Product Type:
Automatic Circuit Breaker
Version:
F
CAD Dimensional Drawing:

Technical

Current Type:
AC
Electrical Durability:
3000 cycle
60 cycles per hour
3000 cycle
60 cycles per hour
Mechanical Durability:
20000 cycle
60 cycles per hour
20000 cycle
60 cycles per hour
Number of Poles:
3P
Order Multiple:
1 piece
Power Loss:
at Rated Operating Conditions per Pole 24 W
Rated Current (In):
800 A
Rated Impulse Withstand Voltage (Uimp):
8 kV
Rated Insulation Voltage (Ui):
1000 V
Rated Operational Voltage:
690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics):
(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 45 kA
(525 V AC) 45 kA
(690 V AC) 30 kA
(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 45 kA
(525 V AC) 45 kA
(690 V AC) 30 kA
Rated Short-time Withstand Current Low Voltage (Icw):
20 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 45 kA
(525 V AC) 45 kA
(690 V AC) 30 kA
(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 45 kA
(525 V AC) 45 kA
(690 V AC) 30 kA
Rated Uninterrupted Current (Iu):
800 A
Release:
Ekip Dip LS/I
Release Type:
EL
Short-Circuit Performance Level:
S
Standards:
IEC60947-2
Sub-type:
XT7M
Terminal Connection Type:
Front

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification Code:
Q
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
15,568.00 kr
1-year warranty
FREE WORDWIDE SHIPPING
Condition:
15,568.00 kr
0.00 kr
0.00 kr
