ABB

1SDA074634R1 ABB

ABB EcoSolutions

ABB EcoSolutions:
Yes
ABB Site Meeting Group Waste To Landfill Target:
UL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions:
Environmental Product Declaration - EPD:
Extended Product Lifetime:
Product Modularity
Recyclability Rate of the Product acc. to EN45555:
Design for Closing Resource Loops - Standard EN45555 - 55.9 %

Material Compliance

RoHS Information:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
3b8fd9bd-deaf-473e-bca3-5c0c0b9666c2 Italy
Simplified SCIP:
28799f78-41f1-43ef-9750-dce0e35fdb5b Germany
17a83770-f822-46a0-802b-dc23c5fc2702 Poland
f4346f45-52c4-49e5-a8d8-54538abdf21d Sweden
84fdcc71-2463-4498-a627-5ca3d638ce43 Germany
ec7ac1dc-189a-4aad-a941-153772199706 Germany
a7073941-102f-4509-97f9-467e041f8055 France
edb9ce8c-6f42-411d-b9f9-fae52dad0622 Netherlands
42d14025-2b5b-4e1b-bce9-2e4932790e5e Spain
1f93601f-134c-4ef2-96d4-de0db226527f Netherlands
cebfbee4-91a3-4bf1-b691-a80c027b1bcf Greece
e09f120e-9e15-4638-b6a2-c0a2e507f345 Czech Republic
2776571a-8624-4643-880f-3e9797cefcae Poland
a89e32b3-4dcf-4644-b29a-942861463b95 Portugal
a6e9759f-6c08-4bf7-bc09-6cf32cd11308 Bulgaria
209b77b7-7ac1-4ec5-a64c-6f27cfc98469 Sweden
c8fdb2ae-42fb-4c38-8e1d-c90275d89238 Poland
08f59948-b88d-445d-bae1-d6f39f054b01 France
6bc169d8-6733-42bd-a5be-82672f29e01b Netherlands
804b311e-c4d0-417e-a70e-0b29ffdc9e4c Netherlands
f819a920-c1ba-441e-94df-037de80cfa36 Estonia
8bc5b015-24e4-446b-837f-7355a98891d5 Germany
4a65bf7b-ceec-40e3-bfd9-5d0b7c839f4c Denmark
3c8c532a-4aa7-4077-a2ec-c5472133443c Germany
a376e9fa-2c7a-4d8c-8895-3e0fb76e7ece Croatia
19082ec1-7c96-4c17-a48f-ea35c831683c Norway
5514ef58-59a4-4242-8385-c98eaa8300f3 Finland
3b5652aa-e465-4976-99c5-5d2cf9e4a0d5 Netherlands
28799f78-41f1-43ef-9750-dce0e35fdb5b Germany
17a83770-f822-46a0-802b-dc23c5fc2702 Poland
f4346f45-52c4-49e5-a8d8-54538abdf21d Sweden
84fdcc71-2463-4498-a627-5ca3d638ce43 Germany
ec7ac1dc-189a-4aad-a941-153772199706 Germany
a7073941-102f-4509-97f9-467e041f8055 France
edb9ce8c-6f42-411d-b9f9-fae52dad0622 Netherlands
42d14025-2b5b-4e1b-bce9-2e4932790e5e Spain
1f93601f-134c-4ef2-96d4-de0db226527f Netherlands
cebfbee4-91a3-4bf1-b691-a80c027b1bcf Greece

Environmental

Environmental Information:

Ordering

Order Code US and Canada:
XT1NU3015AFF000XXX
EAN:
8015644785017
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85362090

Dimensions

Product Net Width:
76.2 mm
Product Net Height:
130 mm
Product Net Depth / Length:
70 mm
Product Net Weight:
1.1 kg

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
128 mm
Package Level 1 Height:
135 mm
Package Level 1 Depth / Length:
143 mm
Package Level 1 Gross Weight:
1.1 kg
Package Level 1 EAN:
8015644785017

Additional Information

Circuit Breaker Type to be Associated:
Power Distribution
Product Main Type:
SACE Tmax XT
Product Name:
Moulded Case Circuit Breaker
Product Type:
Automatic Circuit Breaker
Suitable for Product Class:
SACE Tmax XT
Version:
F
CAD Dimensional Drawing:

Technical

Connecting Capacity Main Circuit:
Busbar 45.5 ... 80 mm²
Current Type:
AC/DC
Electrical Durability:
120 cycles per hour
8000 cycle
120 cycles per hour
8000 cycle
Mechanical Durability:
240 cycles per hour
25000 cycle
240 cycles per hour
25000 cycle
Number of Poles:
3P
Opening Time:
CB with SOR 30 ms
CB with UVR 30 ms
CB with SOR 30 ms
CB with UVR 30 ms
Order Multiple:
1 piece
Power Loss:
at Rated Operating Conditions per Pole 1.1 W
Rated Current (In):
15 A
Rated Instantaneous Short-Circuit Current Setting (Ii):
500 A
Rated Operational Voltage:
600Y/347 V AC
500 V DC
600Y/347 V AC
500 V DC
Rated Uninterrupted Current (Iu):
125 A
Rated Voltage (Ur):
600Y/347 V
Recommended Screw Driver:
Main Circuit M6
Release:
TMF
Release Type:
TM
Setting Range:
15 A
Short-Circuit Performance Level:
N
Standards:
UL489
Sub-type:
XT1
Terminal Connection Type:
Front
Terminal Type:
Bolt
Tightening Torque:
6 N·m

Technical UL/CSA

Interrupting Rating acc. to UL489:
(240 V AC) 50 kA
(480 V AC) 25 kA
(600Y / 347 V AC) 18 kA
(250 V DC) 2 Poles in Series 35 kA
(500 V DC) 4 Poles in Series Kind 35 kA
(240 V AC) 50 kA
(480 V AC) 25 kA
(600Y / 347 V AC) 18 kA
(250 V DC) 2 Poles in Series 35 kA
(500 V DC) 4 Poles in Series Kind 35 kA

Certificates and Declarations

ATEX Certificate:
CSA Certificate (Intrinsic Safe):
Declaration of Conformity - CE:
UL Certificate:
VDE Certificate:
Dimension Diagram:
Mechanical Drawings:
Instructions and Manuals:

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
IDEA Granular Category Code (IGCC):
4927 >> Molded case circuit breakers
Object Classification Code:
Q
UNSPSC:
39121616
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409

Sale price14,565.00 kr
1-year warranty
FREE WORDWIDE SHIPPING
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
Condition:
0.00 kr
14,565.00 kr
12,165.00 kr
