1SDA070782R1 ABB

ABB EcoSolutions

ABB EcoSolutions:
Yes
ABB Site Meeting Group Waste To Landfill Target:
UL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions:
Recyclability Rate of the Product acc. to EN45555:
Design for Closing Resource Loops - Standard EN45555 - 76.4 %

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
dbabcc4e-b0f5-4e1e-8d2b-e12e6cf40099 Italy
Simplified SCIP:
57a95767-a84f-4447-a882-43d3203428bb Germany
83cb26e6-ac2e-4762-a629-b7a8c219c7bf Sweden
2b53e6af-7119-45d4-861f-23b74399fe45 Denmark
77d890f8-44d0-4e1e-b973-483bcf1aab15 Germany
6f0c70b0-859a-423d-ab53-9615b55fb7e3 Germany
24fca232-6c76-4725-828b-c278de6607e9 Poland
b1939112-a908-4bb2-a38b-7b63855ee298 Belgium
52e11229-8da6-47b0-a026-5a4e2dda6cf8 Croatia
83f097f3-8b26-4468-900a-8c3e5122e868 Poland
77d890f8-44d0-4e1e-b973-483bcf1aab15 Germany
9e01a11f-0eed-4ecb-80b7-dec0a6383d8b Germany
2b53e6af-7119-45d4-861f-23b74399fe45 Denmark
2632476e-bcb4-4802-9ded-14d47c9d7472 Poland
be050563-9707-434d-9fea-4a4041fa37d3 Finland
9e01a11f-0eed-4ecb-80b7-dec0a6383d8b Germany
9b17a460-b176-4670-9613-9dc646a0bc19 Norway
9814d24a-bd56-4ea4-bcb4-ee1a4870b347 Portugal
83f097f3-8b26-4468-900a-8c3e5122e868 Poland
4819aa01-2009-4f63-8ced-9c5eed65e085 Belgium
ca4c8b75-dd4b-4287-a6d5-9d32e8136623 Netherlands
24fca232-6c76-4725-828b-c278de6607e9 Poland
52e11229-8da6-47b0-a026-5a4e2dda6cf8 Croatia
6c29752f-2cc5-499b-a5cb-8e57bad85ea7 Hungary
83cb26e6-ac2e-4762-a629-b7a8c219c7bf Sweden
6f0c70b0-859a-423d-ab53-9615b55fb7e3 Germany
ba863063-bc72-4170-a313-95db9d2a5733 Bulgaria
b0a94c2b-c1a6-49b4-8e4b-f25af11aa402 Czech Republic
9b17a460-b176-4670-9613-9dc646a0bc19 Norway
57a95767-a84f-4447-a882-43d3203428bb Germany
b0a94c2b-c1a6-49b4-8e4b-f25af11aa402 Czech Republic
9814d24a-bd56-4ea4-bcb4-ee1a4870b347 Portugal
ad6a82f5-2b08-4c7f-a7ac-ebaf8cf322cc France
be050563-9707-434d-9fea-4a4041fa37d3 Finland
b1939112-a908-4bb2-a38b-7b63855ee298 Belgium
3a4cee54-d479-4413-9d77-825fd09d1e71 Germany
c5c0a50b-31e6-4150-b2c9-1d206289bde5 Estonia
6c29752f-2cc5-499b-a5cb-8e57bad85ea7 Hungary
79871c02-6334-4976-8858-db4689b8d984 Spain
4819aa01-2009-4f63-8ced-9c5eed65e085 Belgium
a2127277-deb2-4470-8caf-cf2204632f79 Hungary
a07caea4-a7a3-48c8-86f9-639750829c37 France
ca22ba67-03dc-4d40-8604-ef5ff9d44629 Sweden
82ba7a2f-f987-4bc9-9d1d-7a56579e8933 Greece
ba863063-bc72-4170-a313-95db9d2a5733 Bulgaria
2632476e-bcb4-4802-9ded-14d47c9d7472 Poland
ca22ba67-03dc-4d40-8604-ef5ff9d44629 Sweden
ad6a82f5-2b08-4c7f-a7ac-ebaf8cf322cc France
3a4cee54-d479-4413-9d77-825fd09d1e71 Germany
a07caea4-a7a3-48c8-86f9-639750829c37 France
c5c0a50b-31e6-4150-b2c9-1d206289bde5 Estonia
a2127277-deb2-4470-8caf-cf2204632f79 Hungary
ca4c8b75-dd4b-4287-a6d5-9d32e8136623 Netherlands
79871c02-6334-4976-8858-db4689b8d984 Spain
82ba7a2f-f987-4bc9-9d1d-7a56579e8933 Greece
57a95767-a84f-4447-a882-43d3203428bb Germany
83cb26e6-ac2e-4762-a629-b7a8c219c7bf Sweden
2b53e6af-7119-45d4-861f-23b74399fe45 Denmark
77d890f8-44d0-4e1e-b973-483bcf1aab15 Germany
6f0c70b0-859a-423d-ab53-9615b55fb7e3 Germany
24fca232-6c76-4725-828b-c278de6607e9 Poland
b1939112-a908-4bb2-a38b-7b63855ee298 Belgium
52e11229-8da6-47b0-a026-5a4e2dda6cf8 Croatia
83f097f3-8b26-4468-900a-8c3e5122e868 Poland
77d890f8-44d0-4e1e-b973-483bcf1aab15 Germany

Environmental

Environmental Information:

Ordering

Order Code US and Canada:
Z1BQEGBB000A000000XX
EAN:
8015644746322
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85362090

Dimensions

Product Net Width:
210 mm
Product Net Height:
296 mm
Product Net Depth / Length:
183 mm
Product Net Weight:
14 kg

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
270 mm
Package Level 1 Height:
350 mm
Package Level 1 Depth / Length:
330 mm
Package Level 1 Gross Weight:
16 kg
Package Level 1 EAN:
8015644746322

Additional Information

Product Main Type:
SACE Emax 2
Product Name:
Air Circuit Breaker
Product Type:
Air Circuit Breaker
Version:
F
CAD Dimensional Drawing:

Technical

Current Type:
AC
Electrical Durability:
Ue =< 440 V 8000 cycle
Ue = 500 ... 690 V 8000 cycle
30 cycles per hour
Ue =< 440 V 8000 cycle
Ue = 500 ... 690 V 8000 cycle
30 cycles per hour
Mechanical Durability:
20000 cycle
60 cycles per hour
20000 cycle
60 cycles per hour
Number of Poles:
3P
Power Loss:
78 W
Rated Current (In):
1000 A
Rated Impulse Withstand Voltage (Uimp):
acc. to IEC 60947-2 12 kV
Rated Insulation Voltage (Ui):
AC 1000 V
Rated Operational Voltage:
690 V AC
Rated Service Short-Circuit Breaking Capacity (Ics):
(220 V AC) 42 kA
(230 V AC) 42 kA
(380 V AC) 42 kA
(400 V AC) 42 kA
(415 V AC) 42 kA
(440 V AC) 42 kA
(500 V AC) 42 kA
(660 V AC) 42 kA
(690 V AC) 42 kA
(220 V AC) 42 kA
(230 V AC) 42 kA
(380 V AC) 42 kA
(400 V AC) 42 kA
(415 V AC) 42 kA
(440 V AC) 42 kA
(500 V AC) 42 kA
(660 V AC) 42 kA
(690 V AC) 42 kA
Rated Service Short-Circuit Breaking Capacity, in % of Icu (Ics):
100 %
Rated Short-time Withstand Current Low Voltage (Icw):
for 1 s 42 kA
for 3 s 24 kA
for 1 s 42 kA
for 3 s 24 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(400 V AC) 42 kA
(415 V AC) 42 kA
(440 V AC) 42 kA
(500 V AC) 42 kA
(525 V AC) 42 kA
(690 V AC) 42 kA
(400 V AC) 42 kA
(415 V AC) 42 kA
(440 V AC) 42 kA
(500 V AC) 42 kA
(525 V AC) 42 kA
(690 V AC) 42 kA
Rated Uninterrupted Current (Iu):
1000 A
Rated Voltage (Ur):
690 V
Recommended Screw Driver:
Main Circuit M10
Release:
Ekip Dip LSI
Release Type:
EL
Short-Circuit Performance Level:
B
Standards:
IEC
Sub-type:
E1.2
Suitable for IT Networks:
Yes, 690V
Terminal Connection Type:
Front
Terminal Type:
Bolt
Tightening Torque:
45 N·m

Certificates and Declarations

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
IDEA Granular Category Code (IGCC):
4926 >> Air circuit breakers
Object Classification Code:
Q
UNSPSC:
39121615
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
Sale price31,852.00 kr
1-year warranty
FREE WORDWIDE SHIPPING
Condition:
31,852.00 kr
0.00 kr
0.00 kr
Ach Direct Debit American Express Apple Pay Diners Club Discover Google Pay Mastercard PayPal Shop Pay Visa
