The ABB 1SDA067399R1 is a three-pole molded case circuit breaker from the SACE Tmax XT1C series, designed for reliable overcurrent protection in low-voltage electrical distribution systems. It features a fixed mounting configuration with front terminals for ease of installation and maintenance. The circuit breaker is equipped with a thermomagnetic TMD release mechanism offering adjustable thermal protection and fixed magnetic trip characteristics with a setting range of 160-1600 A. Rated at 160 A continuous current, the device provides a breaking capacity (Icu) of 25 kA at 415V AC, making it suitable for industrial automation, power distribution panels, and motor control applications. The unit is compatible with voltages up to 690V AC and also supports DC circuit protection. It complies with IEC 60947-2 standards and carries ABB EcoSolutions certification with a recyclability rate of 55.9% according to EN45555. The breaker is RoHS compliant and designed for both AC and DC network protection in demanding industrial environments.
Item Details
- Brand Name: ABB
- Manufacturer: ABB
- Item Type Name: Molded Case Circuit Breaker (MCCB)
- Product Family / Series: SACE Tmax XT
- Series: XT1C
- Frame Size: XT1C 160
- Catalog Description: XT1C 160 TMD 160-1600 3p F F
- Part Number: 1SDA067399R1
- Ean: 8015644012939
Product Specifications
- rated_current: 160 A
- number_of_poles: 3
- breaking_capacity_415v_ac: 25 kA
- breaking_capacity_380v_ac: 25 kA
- breaking_capacity_440v_ac: 25 kA
- breaking_capacity_500v_ac: 18 kA
- breaking_capacity_525v_ac: 8 kA
- breaking_capacity_690v_ac: 4 kA
- breaking_capacity_250v_dc: 25 kA (2 poles in series)
- breaking_capacity_500v_dc: 25 kA (3 poles in series)
- rated_voltage_max: 690 V AC
- release_type: Thermomagnetic (TMD)
- thermal_protection_range: 160-1600 A
- mounting_type: Fixed
- terminal_type: Front terminals (bolt type)
- terminal_connection: M6
- tightening_torque: 6 N·m
- short_circuit_performance: Level C
- standards: IEC 60947-2
Additional Details
- Country of Origin*: IT
- Recyclability Rate: 55.9% (EN45555)
- Rohs Status: Following EU Directive 2011/65/EU and Amendment 2015/863
- Abb Ecosolutions: Yes
- Scip Number: 0d8bc7a2-0b2f-4c4e-b0d2-ae3184d07c12 (Italy)
*Country of origin may vary.
