ABB New Stock Image

1SDA067395R1 ABB

ABB EcoSolutions

ABB EcoSolutions:
Yes
ABB Site Meeting Group Waste To Landfill Target:
UL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions:
Recyclability Rate of the Product acc. to EN45555:
Design for Closing Resource Loops - Standard EN45555 - 55.9 %

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
f8a3db18-b215-4bf0-a188-36b92353ada8 Italy
Simplified SCIP:
4e7a6161-4fb1-4b8a-8a4b-542662f9e352 Germany
61163b89-f1d3-4644-940f-389133811615 Norway
2f6d6e62-1dcc-47cf-ad5c-29c527733f13 France
8f5b62da-4d76-4087-8af5-5e267aa1bcbd Netherlands
a5b18f3c-1c9e-449f-b68a-6bd7c7c24284 Estonia
b5e666e4-dbce-4a12-99f4-267847012e0c Greece
159b8e0c-28d9-4a88-aa7e-aee17a1f5e01 Portugal
49caf4a0-669f-44aa-8705-1686cc584012 Bulgaria
1dee6090-aae8-48be-9df2-02b6bafff9eb Sweden
f5ac57bd-6df7-45cd-8a34-b9742ee54117 Poland
04919024-e6ac-4bbc-8560-440eb1c781e5 Netherlands
4ed2cdb0-2e6d-42d6-8906-e2c821f942f9 Germany
8ae58a5c-dcda-4cc8-a917-fbc2e4708463 Denmark
e2db9e39-108b-408e-8012-427eb24260d6 Germany
7f31893f-1c43-4c83-ac6e-7eaf2f302bc0 Croatia
b25a6819-161b-437b-86d0-3a810a0bf6eb Czech Republic
6f0de107-6c8e-40e8-9ae7-2e6b31050fbe Netherlands
8a56db9b-06ae-49ad-86d5-90505b400768 France
ccb3f727-1d52-4e59-b8bc-31ce6d2020ae Sweden
ac17958f-7474-4c63-8477-7c0aa63eaf38 Germany
86c9d61c-adcf-4e9d-bf83-3823fb1f79d4 Germany
6a7802f3-2cc5-4734-a714-cda6e80b692e Netherlands
73a11258-c80d-4439-ac10-7ff065d2f0d1 Spain
31622732-cbc3-4f89-aa69-1a71dd936b0a Netherlands
cd86e4f0-784b-4f10-80b3-3648eb7dcd8a Poland
aa099d69-662c-40b5-9eca-e20ca28f62b2 Poland
127662e9-0342-459b-9ee2-630c6b565474 Finland
4e7a6161-4fb1-4b8a-8a4b-542662f9e352 Germany
61163b89-f1d3-4644-940f-389133811615 Norway
2f6d6e62-1dcc-47cf-ad5c-29c527733f13 France
8f5b62da-4d76-4087-8af5-5e267aa1bcbd Netherlands
a5b18f3c-1c9e-449f-b68a-6bd7c7c24284 Estonia
b5e666e4-dbce-4a12-99f4-267847012e0c Greece
159b8e0c-28d9-4a88-aa7e-aee17a1f5e01 Portugal
49caf4a0-669f-44aa-8705-1686cc584012 Bulgaria
1dee6090-aae8-48be-9df2-02b6bafff9eb Sweden
f5ac57bd-6df7-45cd-8a34-b9742ee54117 Poland

Environmental

Environmental Information:

Ordering

Order Code US and Canada:
XT1CE3063AFF000XXX
E-Number (Finland):
3638776
E-Number (Norway):
4309615
EAN:
8015644012199
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85362090

Dimensions

Product Net Width:
76.2 mm
Product Net Height:
130 mm
Product Net Depth / Length:
70 mm
Product Net Weight:
1.1 kg

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
128 mm
Package Level 1 Height:
135 mm
Package Level 1 Depth / Length:
143 mm
Package Level 1 Gross Weight:
1.135 kg
Package Level 1 EAN:
8015644012199

Additional Information

Circuit Breaker Type to be Associated:
Power Distribution
Product Main Type:
SACE Tmax XT
Product Name:
Moulded Case Circuit Breaker
Product Type:
Automatic Circuit Breaker
Version:
F
CAD Dimensional Drawing:

Technical

Connecting Capacity Main Circuit:
Busbar 45.5 ... 80 mm²
Current Type:
AC/DC
Electrical Durability:
120 cycles per hour
8000 cycle
120 cycles per hour
8000 cycle
Mechanical Durability:
240 cycles per hour
25000 cycle
240 cycles per hour
25000 cycle
Number of Poles:
3P
Opening Time:
CB with SOR 30 ms
CB with UVR 30 ms
CB with SOR 30 ms
CB with UVR 30 ms
Order Multiple:
1 piece
Power Loss:
at Rated Operating Conditions per Pole 4.3 W
Rated Current (In):
63 A
Rated Frequency (f):
50 / 60 Hz
Rated Impulse Withstand Voltage (Uimp):
8 kV
Rated Instantaneous Short-Circuit Current Setting (Ii):
630 A
Rated Insulation Voltage (Ui):
800 V
Rated Operational Voltage:
690 V AC
500 V DC
690 V AC
500 V DC
Rated Service Short-Circuit Breaking Capacity (Ics):
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 12.5 kA
(500 V AC) 9 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 3 Poles in Series 25 kA
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 12.5 kA
(500 V AC) 9 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 25 kA
(500 V AC) 18 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 3 Poles in Series 25 kA
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 25 kA
(500 V AC) 18 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Uninterrupted Current (Iu):
160 A
Rated Voltage (Ur):
690 V
Recommended Screw Driver:
Main Circuit M6
Release:
TMD
Release Type:
TM
Setting Range:
44.1...63 A
Short-Circuit Performance Level:
C
Standards:
IEC60947-2
Sub-type:
XT1
Terminal Connection Type:
Front
Terminal Type:
Bolt
Tightening Torque:
6 N·m

Certificates and Declarations

ATEX Certificate:
Declaration of Conformity - CE:
GL Certificate:
LR Certificate:
UL Certificate:
VDE Certificate:
Dimension Diagram:
Mechanical Drawings:
Instructions and Manuals:

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification Code:
Q
UNSPSC:
39120000
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
1,319.00 kr
1-year warranty
FREE WORDWIDE SHIPPING
Condition:
1,319.00 kr
0.00 kr
0.00 kr
