ABB New Stock Image

1SDA067394R1 ABB

ABB EcoSolutions

ABB EcoSolutions:
Yes
ABB Site Meeting Group Waste To Landfill Target:
UL 2799 Zero Waste To Landfill Validation available
End Of Life Disassembling Instructions:
Recyclability Rate of the Product acc. to EN45555:
Design for Closing Resource Loops - Standard EN45555 - 55.9 %

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Conflict Minerals Reporting Template (CMRT):
Toxic Substances Control Act - TSCA:
SCIP:
6963f79e-5b3e-491f-8111-ed51582b95f5 Italy
Simplified SCIP:
03623cf1-c0d9-4f9d-a987-0129b1b5c4e3 Germany
0b897293-8966-400d-85d3-3adb67e5645e Netherlands
788f7ce1-ce81-46b1-b516-e8a1a5810a29 Netherlands
aa1def39-a5e1-402c-a7fb-1f69c65bf0cf Germany
75a37be3-c5f2-48d2-921c-196f3e715fbb Denmark
2b729765-22b2-414d-96db-c45c85b86b34 Germany
73e3b539-3241-4e7c-b2e3-a271a8580cce Croatia
f266fe7c-cd54-450c-984b-762ab9f9b7b5 Czech Republic
01bac839-3a95-4abc-9842-01bf939126de Netherlands
6d189084-7c30-4847-b66c-12452df5457e Netherlands
afbc9104-3742-44d7-8a17-ef24c66adf7e Estonia
fa14a73d-5be7-45d6-bea7-eef52df9a461 Greece
c090809c-f591-4fd0-8f91-3f7005422d41 Portugal
8c6a9e39-4f7d-4d91-a84a-7c5fae9fab39 Bulgaria
a751af1f-ba16-4b16-bae1-88bd49a124fd Sweden
189d8f20-fd0b-4ae9-9160-02cedac39911 Poland
dfa00889-9143-4640-beda-7b68e77263b4 France
e2a75877-0b3c-423d-a60d-9205fd4b7277 Sweden
2ba6904a-b275-40a0-a662-5277d2f0e712 Germany
dbbe5839-4af6-41b6-a0d9-d91eb8454cb5 Germany
b8b8214a-1d31-430b-aa6b-829d2c2e0845 Spain
30e0bf90-1472-4e80-9b14-b35167a34379 Netherlands
3fc61ee0-7133-460e-943f-e79dba217b6d Poland
5e5400ef-76f0-49e1-9aff-19542ffb47e1 Poland
1bc8a6dc-76f2-4cd5-8b92-6cd0b382a8e5 Finland
46710f5a-a1b8-4e6f-92eb-28c07b84c61b Norway
ecb4dd9f-7134-4b06-9ce6-ba53c0aceabe France
03623cf1-c0d9-4f9d-a987-0129b1b5c4e3 Germany
0b897293-8966-400d-85d3-3adb67e5645e Netherlands
788f7ce1-ce81-46b1-b516-e8a1a5810a29 Netherlands
aa1def39-a5e1-402c-a7fb-1f69c65bf0cf Germany
75a37be3-c5f2-48d2-921c-196f3e715fbb Denmark
2b729765-22b2-414d-96db-c45c85b86b34 Germany
73e3b539-3241-4e7c-b2e3-a271a8580cce Croatia
f266fe7c-cd54-450c-984b-762ab9f9b7b5 Czech Republic
01bac839-3a95-4abc-9842-01bf939126de Netherlands
6d189084-7c30-4847-b66c-12452df5457e Netherlands

Environmental

Environmental Information:

Ordering

Order Code US and Canada:
XT1CE3050AFF000XXX
E-Number (Finland):
3638609
E-Number (Norway):
4309614
EAN:
8015644695194
Minimum Order Quantity:
1 piece
Customs Tariff Number:
85362090

Dimensions

Product Net Width:
76.2 mm
Product Net Height:
130 mm
Product Net Depth / Length:
70 mm
Product Net Weight:
1.1 kg

Container Information

Package Level 1 Units:
box 1 piece
Package Level 1 Width:
128 mm
Package Level 1 Height:
135 mm
Package Level 1 Depth / Length:
143 mm
Package Level 1 Gross Weight:
1.12 kg
Package Level 1 EAN:
8015644695194

Additional Information

Circuit Breaker Type to be Associated:
Power Distribution
Product Main Type:
SACE Tmax XT
Product Name:
Moulded Case Circuit Breaker
Product Type:
Automatic Circuit Breaker
Version:
F
CAD Dimensional Drawing:

Technical

Connecting Capacity Main Circuit:
Busbar 45.5 ... 80 mm²
Current Type:
AC/DC
Electrical Durability:
120 cycles per hour
8000 cycle
120 cycles per hour
8000 cycle
Mechanical Durability:
240 cycles per hour
25000 cycle
240 cycles per hour
25000 cycle
Number of Poles:
3P
Opening Time:
CB with SOR 30 ms
CB with UVR 30 ms
CB with SOR 30 ms
CB with UVR 30 ms
Order Multiple:
1 piece
Power Loss:
at Rated Operating Conditions per Pole 3.7 W
Rated Current (In):
50 A
Rated Frequency (f):
50 / 60 Hz
Rated Impulse Withstand Voltage (Uimp):
8 kV
Rated Instantaneous Short-Circuit Current Setting (Ii):
500 A
Rated Insulation Voltage (Ui):
800 V
Rated Operational Voltage:
690 V AC
500 V DC
690 V AC
500 V DC
Rated Service Short-Circuit Breaking Capacity (Ics):
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 12.5 kA
(500 V AC) 9 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 3 Poles in Series 25 kA
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 12.5 kA
(500 V AC) 9 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Ultimate Short-Circuit Breaking Capacity (Icu):
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 25 kA
(500 V AC) 18 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
(500 V DC) 3 Poles in Series 25 kA
(220 V AC) 40 kA
(230 V AC) 40 kA
(240 V AC) 40 kA
(380 V AC) 25 kA
(415 V AC) 25 kA
(440 V AC) 25 kA
(500 V AC) 18 kA
(525 V AC) 8 kA
(690 V AC) 4 kA
(250 V DC) 2 Poles in Series 25 kA
Rated Uninterrupted Current (Iu):
160 A
Rated Voltage (Ur):
690 V
Recommended Screw Driver:
Main Circuit M6
Release:
TMD
Release Type:
TM
Setting Range:
35...50 A
Short-Circuit Performance Level:
C
Standards:
IEC60947-2
Sub-type:
XT1
Terminal Connection Type:
Front
Terminal Type:
Bolt
Tightening Torque:
6 N·m

Certificates and Declarations

ATEX Certificate:
Declaration of Conformity - CE:
GL Certificate:
LR Certificate:
UL Certificate:
VDE Certificate:
Dimension Diagram:
Mechanical Drawings:
Instructions and Manuals:

External Classifications and Standards

ETIM 9:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
ETIM 10:
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Object Classification Code:
Q
UNSPSC:
39120000
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
eClass:
V11.1 : 27370409
Est. delivery between and
Estimated delivery dates are estimates only. Int'l customers allow a few more days. For more precise delivery estimates, please contact us at support@plc-direct.com. Contact us in advance for expedited shipping options.
1,319.00 kr
1-year warranty
FREE WORDWIDE SHIPPING
Condition:
1,319.00 kr
0.00 kr
0.00 kr
