The Siemens 1FK7086-7AF71-1SA0-Z is a SIMOTICS S-1FK7 high dynamic synchronous (permanent-magnet) servomotor from the 1FK7 Generation 2 family, designed for use with SINAMICS S120 drive systems. It belongs to the shaft-height 80 mm frame (1FK7086) compact-design class and is intended for demanding motion-control applications such as machine tools, production machinery, packaging, handling and robotics where high dynamic response, smooth running and precise positioning are required. The motor uses a three-phase stator with rare-earth permanent magnets in the rotor, natural cooling, and integrated electronic identification via the DRIVE-CLiQ encoder interface. The order code suffix 1SA0 indicates an absolute encoder (single-turn, DRIVE-CLiQ) with a plain shaft end (without feather key) and no holding brake; the trailing -Z denotes additional factory-configured options specified at the time of order.
Item Details
- Brand Name: Siemens
- Manufacturer: Siemens AG
- Item Type Name: AC Synchronous Servo Motor
- Product Family / Series: SIMOTICS S-1FK7 (Generation 2) High Dynamic Synchronous Servomotor
- Compatible Drive System: SINAMICS S120
- Motor Type: Permanent-magnet synchronous (PMSM) servo motor
- Cooling Method: Natural cooling (convection)
- Encoder Type: Absolute encoder, single-turn, with DRIVE-CLiQ interface (code 'S')
- Shaft Design: Plain shaft end, without feather key (code 'A')
- Holding Brake: Without holding brake (code '0')
- Options Indicator: -Z (factory-configured supplementary options)
Product Specifications
- shaft_height: 80 mm
- number_of_pole_pairs: 4
- rated_speed: 3000 rpm
- maximum_speed: 4500 rpm
- static_torque_(M0): 23 Nm
- rated_current_at_stall_(I0): 23.5 A
- maximum_torque: 51.8 Nm
- maximum_current: Approx. 4× I0
- rotor_moment_of_inertia: 0.0204 kg·m² (×10⁻³ as per datasheet: 23×10⁻³ kg·m²·10⁻¹)
- voltage_rating_(DC_link): 600 V DC (SINAMICS S120 typical)
- phases: 3-phase AC
- insulation_class: Class F (155 °C)
- protection_class: IP64 (standard for 1FK7 with radial shaft sealing ring)
- winding_code_AF: AF = 3000 rpm rated speed at 400 V line
Additional Details
- Country of Origin*: Germany / Czech Republic (Siemens AG manufacturing)
- Lifecycle Status: Active product (1FK7 Generation 2)
- Ambient Temperature Range: 0 to 40 °C (standard)
- Mounting: IM B5 (flange) standard; IM V1 / IM V3 also available
- Vibration Severity Grade: Grade A (per EN 60034-14)
- Applications: Machine tools, production machines, packaging, handling, robotics, printing
*Country of origin may vary.
Measurements
- Frame Size: Shaft height 80 mm
- Weight Without Brake: Approx. 23 kg (typical for 1FK7086 natural-cooled)
