Residual Current Circuit Breakers

292 products

Showing 265 - 288 of 292 products

Showing 265 - 288 of 292 products
View
2CSM236913R0801 ABB - TM-C 1000/115-230
ABB 2CSM236913R0801 ABB - TM-C 1000/115-230
0.00 kr
Sold Out

Technical

Power Supply:
1000 V·A
Insulation Class:
F
Fuse Type:
aM
Material of Conductor:
Copper
Cable Cross-Section:
6 mm²

Electrical

Rated Insulation Voltage (Ui):
3.5 kV
Primary Voltage:
230-400 V AC
Secondary Voltage:
115-230 V AC
Rated Frequency (f):
50/60 Hz
Power Loss:
60 W

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU
RoHS Date:
20190722
REACH Information:
False - does not contain substances > 0.1 mass percentage
REACH Date:
20240429
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Business

Environmental

Ambient Temperature:
max. 40 °C
Environmental Information:

Dimensions

Product Net Width:
155 mm
Product Net Height:
205 mm
Product Net Depth / Length:
168 mm
Product Net Weight:
13.2 kg

Ordering

Package Level 1 Units:
box 1 piece
Package Level 1 Gross Weight:
13.2 kg

Certificates and Declarations

Declaration of Conformity - CE:

Popular Downloads

Inrush Power Curve:
Transformer Protection Selection Table:
Power Draw According to Altitude:
Power Draw According to Temperature:
Admissible Overload:

External Classifications and Standards

ETIM 9:
EC002486 - One-phase control transformer
ETIM 10:
EC002486 - One-phase control transformer
eClass:
V11.0 : 27031302
Object Classification Code:
T
Standards:
EN 61558-2-2 , UL506 , CSA C22-2-N66
Certification Agency:
ENEC
UR
RINA
ENEC
UR
RINA
Standardization Body:
CSA
2CSM204802R1801 ABB - E 93/30 J
ABB 2CSM204802R1801 ABB - E 93/30 J
0.00 kr
Sold Out

Technical

Suitable For:
E 90
Suitable for Product Class:
Fuse holders
Number of Protected Poles:
3
Number of Poles:
3P
Tightening Torque:
3.5-4 N·m
Lock Type:
Padlockable
Sealing Type:
Sealing Wire
Material of Conductor:
Copper
Options Provided:
No
Recommended Screw Driver:
Pozidriv 2
Remarks:
For use with CU only 60°C or 75°C wire
Shock and Vibration Withstand acc. to IEC 61373:
Category 1, Class B
Fuse Size:
22x58 mm
Operating Humidity (RHamb):
max. 90% at +20 °C
50% at max. +40 °C
max. 90% at +20 °C
50% at max. +40 °C

Electrical

Rated Voltage (Ur):
600 V
Rated Insulation Voltage (Ui):
1+2*Un kV
Rated Current (In):
30 A
Current Range:
1-30 A
Rated Frequency (f):
60 Hz

Technical UL/CSA

Connecting Capacity UL/CSA:
Stranded 1x14…1 AWG
Stranded 2x14…8 AWG
Rigid 1x14…10 AWG
Rigid 2x14…10 AWG
Stranded 1x14…1 AWG
Stranded 2x14…8 AWG
Rigid 1x14…10 AWG
Rigid 2x14…10 AWG
Tightening Torque UL/CSA:
31-35 in·lb

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU
RoHS Date:
20190722
REACH Information:
True - contains substances > 0.1 mass percentage
REACH Date:
20240429
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Business

Environmental

Ambient Air Temperature:
Operation -5...+40 °C
Storage -25...+70 °C
Operation -5...+40 °C
Storage -25...+70 °C
Resistance to Vibrations:
1 mm 2 … 13 Hz
Resistance to Shock acc. to IEC 60068-2-27:
15g 18 shocks 11 ms
Environmental Information:

Dimensions

Width in Number of Modular Spacings:
6
Product Net Width:
105 mm
Product Net Height:
112 mm
Product Net Depth / Length:
73.26 mm
Product Net Weight:
405 g
Built-In Depth (t2):
73.26 mm

Ordering

Package Level 1 Units:
box 6 piece
Package Level 1 Gross Weight:
0.405 kg

Certificates and Declarations

Declaration of Conformity - CE:
UL Certificate:

Installation

Mounting Type:
DIN-Rail

Popular Downloads

External Classifications and Standards

ETIM 9:
EC002705 - Holder for cylindrical fuse
ETIM 10:
EC002705 - Holder for cylindrical fuse
UNSPSC:
39121624
eClass:
V11.0 : 27142121
IDEA Granular Category Code (IGCC):
4974 >> Holder for cylindrical fuse
Object Classification Code:
F
Standards:
UL 4248-1
UL 4248-8
UL 4248-1
UL 4248-8
Standardization Body:
UL
2CSK1312CH ABB
ABB 2CSK1312CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Mounting Type:
Flush Mounted
Type of Fastening:
Engage (Snap)

Environmental

Degree of Protection:
IP20

Technical

Data Sheet, Technical Information:
Lamp Type:
Glow lamp
Illumination:
Illuminated
Lamp Color:
Red

Electrical

Rated Voltage (Ur):
230 V
Power Watt:
0.4 W

Design

Design Range:
Chiara
Surface Finishing:
Surface protection: Lacquered, Surface finishing: Matt
Material:
Material quality: Thermoplastic, Material: Plastic
RAL Number:
RAL 9003 - Signal White
Color:
White
Number of Modules:
1

Dimensions

Width in Number of Modular Spacings:
1
Product Net Width:
0.05 m
Product Net Height:
20 m
Product Net Depth / Length:
20 m
Product Net Weight:
0.001 kg
Built-In Depth (t2):
35 mm

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
3. Lamps
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

External Classifications and Standards

ETIM 9:
EC000064 - Information light signal for domestic switching devices
ETIM 10:
EC000064 - Information light signal for domestic switching devices
2CSE1103EL ABB
ABB 2CSE1103EL ABB
0.00 kr
Sold Out

gray 10/16a ??bypass socket
2CSK0313CH ABB
ABB 2CSK0313CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Type of Fastening:
Clamp
Mounting Orientation:
Horizontal

Environmental

Degree of Protection:
IP20

Technical

Data Sheet, Technical Information:
Illumination:
Non-illuminated

Design

Design Range:
Chiara
Surface Finishing:
Basic
Material:
Thermoplastic
Plastic
Thermoplastic
Plastic
Label Space Provided:
With Label Space
Color:
Green
Number of Gangs:
1-gang
Number of Modules:
Horizontal 3
Vertical 0
Horizontal 3
Vertical 0

Dimensions

Width in Number of Modular Spacings:
3
Product Net Width:
119 mm
Product Net Height:
92 mm
Product Net Depth / Length:
11.5 mm
Product Net Weight:
0.003 kg

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
Product Not in WEEE Scope
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

Declaration of Conformity - CE:

External Classifications and Standards

ETIM 9:
EC000007 - Cover frame for domestic switching devices
ETIM 10:
EC000007 - Cover frame for domestic switching devices
ABB Stock Image
ABB 2CSM204375R1341 ABB
0.00 kr
Sold Out

PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
2CSK1122CH ABB
ABB 2CSK1122CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Mounting Type:
Clip
Type of Fastening:
Engage (Snap)

Environmental

Degree of Protection:
IP20

Technical

Data Sheet, Technical Information:
Communication Connector Type:
RJ12 6(6)
Connection Type:
LSA
Socket Outlet Type:
Data Socket Outlets - Telephone RJ12
Outlet Orientation:
Straight
Illumination:
Non-illuminated

Design

Design Range:
Chiara
Surface Finishing:
Basic
Material:
Plastic
RAL Number:
RAL 9003 - Signal White
Color:
White

Dimensions

Width in Number of Modular Spacings:
1
Product Net Width:
25 mm
Product Net Height:
45 mm
Product Net Depth / Length:
27 mm
Product Net Weight:
0 kg

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

External Classifications and Standards

ETIM 9:
EC001264 - Data communication connection box copper (twisted pair)
ETIM 10:
EC001264 - Data communication connection box copper (twisted pair)
2CSM279022R1801 ABB - E 91/50
ABB 2CSM279022R1801 ABB - E 91/50
0.00 kr
Sold Out

Technical

Suitable For:
E 90
Suitable for Product Class:
Fuse holders
Number of Protected Poles:
1
Number of Poles:
1P
Tightening Torque:
3...3.5 N·m
Utilization Category:
Connecting and disconnecting under no-load conditions - occasional actuation (AC-20B)
Lock Type:
Padlockable
Sealing Type:
Sealing Wire
Material of Conductor:
Copper
Options Provided:
No
Recommended Screw Driver:
Pozidriv 2
Connecting Capacity:
Rigid 2.5…25 mm²
Rigid Stranded|2.5…35 mm²
Rigid 2.5…25 mm²
Rigid Stranded|2.5…35 mm²
Fuse Size:
14x51 mm
Operating Humidity (RHamb):
max. 90% with temp. +20 °C|50% with max. temp. +40 °C
Rated Operational Current AC (Ie):
50 A

Electrical

Rated Voltage (Ur):
acc. To IEC 690 V
acc. To UL 690 V
acc. To IEC 690 V
acc. To UL 690 V
Rated Operational Voltage:
AC-20B 690 V
Rated Insulation Voltage (Ui):
1 kV
Rated Frequency (f):
50/60 Hz
Power Loss:
at Rated Operating Conditions per Pole 5 W

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
01/01/2014 0.00.00
REACH Information:
True - contains substances > 0.1 mass percentage
REACH Date:
20240429
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Environmental

Ambient Air Temperature:
Storage -5...+40 °C
Storage Operation|-25...+70 °C
Storage -5...+40 °C
Storage Operation|-25...+70 °C
Degree of Protection:
IP20
Resistance to Vibrations:
1 mm 2 … 13 Hz
Resistance to Shock acc. to IEC 60068-2-27:
15g 18 shocks 11 ms
Environmental Information:

Dimensions

Width in Number of Modular Spacings:
1.5
Product Net Width:
26.7 mm
Product Net Height:
96.5 mm
Product Net Depth / Length:
73.26 mm
Product Net Weight:
95 g
Built-In Depth (t2):
73.26 mm

Ordering

Package Level 1 Units:
box 4 piece
Package Level 1 Gross Weight:
0.38 kg
E-Number (Finland):
3017008
E-Number (Norway):
1416150

Installation

Mounting Type:
DIN-Rail

Popular Downloads

External Classifications and Standards

ETIM 9:
EC002705 - Holder for cylindrical fuse
ETIM 10:
EC002705 - Holder for cylindrical fuse
UNSPSC:
39121624
eClass:
V11.0 : 27142121
IDEA Granular Category Code (IGCC):
4974 >> Holder for cylindrical fuse
Object Classification Code:
F
Certification Agency:
BV
Korean register
CCC
EAC
BV
Korean register
CCC
EAC
Standardization Body:
UL
2CSK1008CH ABB
ABB 2CSK1008CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Mounting Type:
Flush Mounted
Type of Fastening:
Screw

Environmental

Degree of Protection:
IP55

Technical

Data Sheet, Technical Information:
Function:
Function lighting: Illuminated (on)
Number of Poles:
1P
Number of Rocker Switches:
2
Wiring Configuration:
Intermediate switch
Actuator Type:
Rocker/button
Connection Type:
Screw
Illumination:
Illuminated

Electrical

Rated Voltage (Ur):
250 V
Rated Current (In):
16 A
Maximum Switching Current:
Fluorescent Lamps 16

Design

Design Range:
Chiara
Surface Finishing:
Plastic
Matt
Plastic
Matt
Material:
Plastic
Label Space Provided:
Without Label Space
Color:
White
Number of Modules:
2

Dimensions

Width in Number of Modular Spacings:
2
Product Net Width:
44 mm
Product Net Height:
45 mm
Product Net Depth / Length:
48 mm
Product Net Weight:
0.003 kg
Built-In Depth (t2):
42 mm

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

Declaration of Conformity - CE:

External Classifications and Standards

ETIM 9:
EC001590 - Installation switch
ETIM 10:
EC001590 - Installation switch
2CSM260043R0801 ABB - TM-S 200/12-24 P
ABB 2CSM260043R0801 ABB - TM-S 200/12-24 P
0.00 kr
Sold Out

Technical

Power Supply:
200 V·A
Insulation Class:
F
Fuse Type:
aM
Material of Conductor:
Copper
Cable Cross-Section:
6 mm²

Electrical

Rated Insulation Voltage (Ui):
4.8 kV
Primary Voltage:
230-400 ±15 V AC
Secondary Voltage:
12-24 V AC
Rated Frequency (f):
50/60 Hz
Power Loss:
21 W

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU
RoHS Date:
20190722
REACH Information:
False - does not contain substances > 0.1 mass percentage
REACH Date:
20240429
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Business

Environmental

Ambient Temperature:
max. 40 °C
Environmental Information:

Dimensions

Product Net Width:
100 mm
Product Net Height:
89 mm
Product Net Depth / Length:
90 mm
Product Net Weight:
3.2 kg

Ordering

Package Level 1 Units:
box 1 piece
Package Level 1 Gross Weight:
3.2 kg

Certificates and Declarations

Declaration of Conformity - CE:

Popular Downloads

Inrush Power Curve:
Transformer Protection Selection Table:
Power Draw According to Altitude:
Power Draw According to Temperature:
Admissible Overload:

External Classifications and Standards

ETIM 9:
EC002486 - One-phase control transformer
ETIM 10:
EC002486 - One-phase control transformer
eClass:
V11.0 : 27031302
Object Classification Code:
T
Standards:
EN 61558-2-2, EN 61558-2-6 , UL506 , CSA C22-2-N66
Certification Agency:
ENEC
UR
ENEC
UR
Standardization Body:
CSA
2CSK1014CH ABB
ABB 2CSK1014CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:

Environmental

Degree of Protection:
IP20

Technical

Data Sheet, Technical Information:
Number of Poles:
1P
Polarity:
Negative
Switching Technique:
Monostable
Connection Type:
Spring Clamp
Illumination:
Non-illuminated

Electrical

Rated Control Supply Voltage (Us):
(50 Hz) 230...230 V
(60 Hz) 230...230 V
(50 Hz) 230...230 V
(60 Hz) 230...230 V
Input Voltage Type:
AC
Rated Current (In):
10 A
Number of Contacts CO:
0
Number of Contacts NO:
1

Design

Design Range:
Chiara
Surface Finishing:
Basic
Material:
Plastic
Color:
White

Dimensions

Width in Number of Modular Spacings:
1
Product Net Width:
22 mm
Product Net Height:
45 mm
Product Net Depth / Length:
48 mm
Product Net Weight:
0 kg

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

External Classifications and Standards

ETIM 9:
EC001437 - Switching relay
ETIM 10:
EC001437 - Switching relay
2CSM210000R0701 ABB M1170
ABB 2CSM210000R0701 ABB M1170
0.00 kr
Sold Out

Technical

Number of Active Pin Terminals:
2
Tightening Torque:
1.2 N·m
Product Type:
Italian dual Standard
Options Provided:
Safety shutters
Cable Cross-Section:
Minimum 2.5 mm²
Maximum 16 mm²
Minimum 2.5 mm²
Maximum 16 mm²
Connecting Capacity:
Rigid Cu-Cable 2.5 ... 16 mm²

Electrical

Rated Voltage (Ur):
250 V AC
Rated Current (In):
16 A
Rated Frequency (f):
50/60 Hz
Power Loss:
at Rated Operating Conditions per Pole 0.6 W

Design

Color:
Grey

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
20211115
REACH Information:
False - does not contain substances > 0.1 mass percentage
REACH Date:
20250225
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Environmental

Ambient Air Temperature:
Operation -25…+35 °C
Storage -40…+70 °C
Operation -25…+35 °C
Storage -40…+70 °C
Degree of Protection:
IP20
Environmental Information:

Dimensions

Width in Number of Modular Spacings:
2.5
Product Net Width:
44 mm
Product Net Height:
85 mm
Product Net Depth / Length:
70 mm
Product Net Weight:
0.089 kg
Built-In Depth (t2):
60 mm

Ordering

Package Level 1 Units:
4 piece
Package Level 1 Gross Weight:
0.402 kg

Certificates and Declarations

Declaration of Conformity - CE:

Installation

Popular Downloads

External Classifications and Standards

ETIM 9:
EC001663 - Socket outlet for distribution board
ETIM 10:
EC001663 - Socket outlet for distribution board
eClass:
V11.0 : 27142305
Object Classification Code:
X
2CSM110000R1011 ABB - VLMD-1-2
ABB 2CSM110000R1011 ABB - VLMD-1-2
0.00 kr
Sold Out

VLMD-1-2 Digital Voltmeter
2CSM100090R1111 ABB - TRFM/100
ABB 2CSM100090R1111 ABB - TRFM/100
0.00 kr
Sold Out

Technical

Current Rating:
100 A
Rated Primary Current (Ipn):
100 A
Rated Secondary Current (Isn):
5 A
Current Limit Function:
FS 5
Apparent Power Output:
5 V·A
Secondary Output Connection:
Plug-in connection
Model Number:
Through-feed current converter
Number of Inputs:
Primary 1

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
20230928
REACH Information:
No data - If REACH inform is not yet available for a certain product
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Environmental

Degree of Protection:
IP20
Environmental Information:

Dimensions

Product Net Width:
0.065 m
Product Net Height:
0.075 m
Product Net Depth / Length:
0.100 m
Product Net Weight:
0.187 kg
Bore Diameter:
30 mm

Ordering

Package Level 1 Units:
box 1 piece
Package Level 1 Gross Weight:
0.217 kg
E-Number (Finland):
6701046
E-Number (Norway):
8261072

Certificates and Declarations

Declaration of Conformity - CE:

Installation

Mounting Type:
DIN-Rail

Popular Downloads

Data Sheet, Technical Information:

External Classifications and Standards

ETIM 9:
EC002048 - Current transformer
ETIM 10:
EC002048 - Current transformer
eClass:
V11.0 : 27210902
Object Classification Code:
T
2CSM204922R1801 ABB - E 93/125s
ABB 2CSM204922R1801 ABB - E 93/125s
0.00 kr
Sold Out

Technical

Suitable For:
E 90
Suitable for Product Class:
Fuse holders
Number of Protected Poles:
3
Number of Poles:
3P
Tightening Torque:
3.5...4 N·m
Utilization Category:
Connecting and disconnecting under no-load conditions - occasional actuation (AC-20B)
Lock Type:
Padlockable
Sealing Type:
Sealing Wire
Material of Conductor:
Copper
Options Provided:
With LED
Recommended Screw Driver:
Pozidriv 2
Connecting Capacity:
Rigid 4…35 mm²
Rigid Stranded|4…50 mm²
Rigid 4…35 mm²
Rigid Stranded|4…50 mm²
Fuse Size:
22x58 mm
Operating Humidity (RHamb):
max. 90% with temp. +20 °C|50% with max. temp. +40 °C
Rated Operational Current AC (Ie):
125 A

Electrical

Rated Voltage (Ur):
acc. To IEC 690 V
acc. To UL 690 V
acc. To IEC 690 V
acc. To UL 690 V
Rated Operational Voltage:
AC-20B 690 V
Rated Insulation Voltage (Ui):
1 kV
Rated Frequency (f):
50/60 Hz
Power Loss:
at Rated Operating Conditions per Pole 9.5 W

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
01/01/2014 0.00.00
REACH Information:
True - contains substances > 0.1 mass percentage
REACH Date:
20240429
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Business

Environmental

Ambient Air Temperature:
Storage -5...+40 °C
Storage Operation|-25...+70 °C
Storage -5...+40 °C
Storage Operation|-25...+70 °C
Degree of Protection:
IP20
Resistance to Vibrations:
1 mm 2 … 13 Hz
Resistance to Shock acc. to IEC 60068-2-27:
15g 18 shocks 11 ms
Environmental Information:

Dimensions

Width in Number of Modular Spacings:
6
Product Net Width:
105 mm
Product Net Height:
112 mm
Product Net Depth / Length:
73.26 mm
Product Net Weight:
405 g
Built-In Depth (t2):
73.26 mm

Ordering

Package Level 1 Units:
box 2 piece
Package Level 1 Gross Weight:
0.54 kg
E-Number (Norway):
1416168

Installation

Mounting Type:
DIN-Rail

Popular Downloads

External Classifications and Standards

ETIM 9:
EC002705 - Holder for cylindrical fuse
ETIM 10:
EC002705 - Holder for cylindrical fuse
UNSPSC:
39121624
eClass:
V11.0 : 27142121
IDEA Granular Category Code (IGCC):
4974 >> Holder for cylindrical fuse
Object Classification Code:
F
Certification Agency:
BV
Korean register
CCC
EAC
BV
Korean register
CCC
EAC
Standardization Body:
UL
2CSM110229R1041 ABB - SCL 1/200
ABB 2CSM110229R1041 ABB - SCL 1/200
0.00 kr
Sold Out

SCL 1/200 Scale for analogue ammeter
2CSK2240CH ABB - IP40 enclosure, 2 places, 2 modules width Grey - Chiara
ABB 2CSK2240CH ABB - IP40 enclosure, 2 places, 2 modules width Grey - Chiara
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Mounting Type:
Wall-/ceiling mounting

Environmental

Degree of Protection:
IP40

Technical

Data Sheet, Technical Information:
Number of Conduit Inlets:
2
Cover Mounting Type:
Screw
Entrance Type:
Type of housing feed-through: Seal membrane
Illumination:
Non-illuminated
Includes:
Clamp

Design

Design Range:
Chiara
Shape:
Square
Surface Finishing:
Basic
Material:
Plastic
Cover Style:
Mounting Cover
RAL Number:
RAL 7035 - Light Grey
Color:
Grey

Dimensions

Width in Number of Modular Spacings:
2
Product Net Width:
65 mm
Product Net Height:
60 m
Product Net Depth / Length:
55 mm
Product Net Weight:
0.007 kg

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
Product Not in WEEE Scope
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

Declaration of Conformity - CE:

External Classifications and Standards

ETIM 9:
EC002600 - Box/housing for surface mounting on the wall/ceiling
ETIM 10:
EC002600 - Box/housing for surface mounting on the wall/ceiling
2CSK2255CH ABB
ABB 2CSK2255CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Mounting Type:
Wall-/ceiling mounting

Environmental

Degree of Protection:
IP55

Technical

Data Sheet, Technical Information:
Number of Conduit Inlets:
2
Cover Mounting Type:
Hinged
Entrance Type:
Type of housing feed-through: Seal membrane
Illumination:
Non-illuminated
Includes:
Clamp

Design

Design Range:
Chiara
Shape:
Square
Surface Finishing:
Basic
Material:
Plastic
Cover Style:
Blind Cover
RAL Number:
RAL 7035 - Light Grey
Color:
Grey

Dimensions

Width in Number of Modular Spacings:
2
Product Net Width:
65 mm
Product Net Height:
60 m
Product Net Depth / Length:
63 mm
Product Net Weight:
0.01 kg

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
Product Not in WEEE Scope
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

Declaration of Conformity - CE:

External Classifications and Standards

ETIM 9:
EC002600 - Box/housing for surface mounting on the wall/ceiling
ETIM 10:
EC002600 - Box/housing for surface mounting on the wall/ceiling
2CSM232275N0001 ABB - WLC101X
ABB 2CSM232275N0001 ABB - WLC101X
0.00 kr
Sold Out

Installation

Technical

Dimensions

Product Net Width:
0.07 mm
Product Net Height:
0.28 mm
Product Net Depth / Length:
0.28 mm
Product Net Weight:
304 g

Material Compliance

REACH Information:
No data - If REACH inform is not yet available for a certain product
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

External Classifications and Standards

ETIM 9:
EC002971 - System device clinic-installation
ETIM 10:
EC002971 - System device clinic-installation
2CSM112000R0701 ABB - M1173-L
ABB 2CSM112000R0701 ABB - M1173-L
0.00 kr
Sold Out

Technical

Number of Active Pin Terminals:
2
Tightening Torque:
1.2 N·m
Lamp Type:
Fluorescent torpedo-shaped lamp
Product Type:
Italian P30 Standard
Options Provided:
Indicator light for power supply presence
Safety shutters
Indicator light for power supply presence
Safety shutters
Lamp Color:
Green
Cable Cross-Section:
Minimum 2.5 mm²
Maximum 16 mm²
Minimum 2.5 mm²
Maximum 16 mm²
Connecting Capacity:
Rigid Cu-Cable 2.5 ... 16 mm²

Electrical

Rated Voltage (Ur):
250 V AC
Rated Current (In):
16 A
Rated Frequency (f):
50/60 Hz
Power Consumption (@Pcons):
Indicator Light 0.25 W
Power Loss:
at Rated Operating Conditions per Pole 0.6 W

Design

Color:
Grey

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
RoHS Date:
20211115
REACH Information:
False - does not contain substances > 0.1 mass percentage
REACH Date:
20250225
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Environmental

Ambient Air Temperature:
Operation -25…+35 °C
Storage -40…+70 °C
Operation -25…+35 °C
Storage -40…+70 °C
Degree of Protection:
IP20
Environmental Information:

Dimensions

Width in Number of Modular Spacings:
2.5
Product Net Width:
44 mm
Product Net Height:
85 mm
Product Net Depth / Length:
70 mm
Product Net Weight:
0.093 kg
Built-In Depth (t2):
60 mm

Ordering

Package Level 1 Units:
4 piece
Package Level 1 Gross Weight:
0.419 kg

Certificates and Declarations

Declaration of Conformity - CE:
IMQ Certificate:

Installation

Popular Downloads

External Classifications and Standards

ETIM 9:
EC001663 - Socket outlet for distribution board
ETIM 10:
EC001663 - Socket outlet for distribution board
eClass:
V11.0 : 27142305
Object Classification Code:
X
Certification Agency:
IMQ
2CSM244000R1501 ABB - ISOLTESTER-DIG-RZ
ABB 2CSM244000R1501 ABB - ISOLTESTER-DIG-RZ
0.00 kr
Sold Out

Technical

Evaluation Inputs:
Three Channel
Model Number:
Basic device
Delay Time (τ):
Release 0...0 second [unit of time]

Electrical

Rated Control Supply Voltage (Us):
24...230 V AC
Power Consumption (@Pcons):
At Rated Load 5 V·A
Power Loss:
4.5 W

Material Compliance

RoHS Status:
Following EU Directive 2011/65/EU
RoHS Date:
20180713
Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Environmental

Environmental Information:

Dimensions

Product Net Width:
90 mm
Product Net Height:
90 mm
Product Net Depth / Length:
105 mm
Product Net Weight:
450 g

Ordering

Package Level 1 Units:
box 1 piece
Package Level 1 Gross Weight:
0.5 kg
Replacement Product ID (NEW):
2CSM257905R1501

Certificates and Declarations

Declaration of Conformity - CE:

Installation

Instructions and Manuals:

External Classifications and Standards

ETIM 9:
EC001449 - Device for monitoring of safety-related circuits
ETIM 10:
EC001449 - Device for monitoring of safety-related circuits
eClass:
V11.0 : 27371819
Object Classification Code:
F
2CSK1625CH ABB
ABB 2CSK1625CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Type of Fastening:
Screw
Mounting Orientation:
Horizontal

Environmental

Degree of Protection:
IP20

Technical

Data Sheet, Technical Information:
Illumination:
Non-illuminated

Design

Design Range:
Chiara
Surface Finishing:
Basic
Material:
Thermoplastic
Plastic
Thermoplastic
Plastic
Label Space Provided:
Without Label Space
Color:
Black
Number of Gangs:
1-gang
Number of Modules:
Horizontal 5
Vertical 0
Horizontal 5
Vertical 0

Dimensions

Width in Number of Modular Spacings:
5
Product Net Width:
93.4 mm
Product Net Height:
42 mm
Product Net Depth / Length:
34 mm
Product Net Weight:
0 kg

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
Product Not in WEEE Scope
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

Declaration of Conformity - CE:

External Classifications and Standards

ETIM 9:
EC000007 - Cover frame for domestic switching devices
ETIM 10:
EC000007 - Cover frame for domestic switching devices
2CSK1606CH ABB
ABB 2CSK1606CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Type of Fastening:
Clamp

Environmental

Degree of Protection:
IP55

Technical

Data Sheet, Technical Information:
Application:
Switch/push button
Illumination:
Non-illuminated

Design

Design Range:
Chiara
Surface Finishing:
Lacquered
Matt
Lacquered
Matt
Material:
Plastic
Legend:
Without imprint
RAL Number:
RAL 9003 - Signal White
Color:
White

Dimensions

Width in Number of Modular Spacings:
1
Product Net Width:
22 mm
Product Net Height:
45 mm
Product Net Depth / Length:
10 mm
Product Net Weight:
0 kg

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
Product Not in WEEE Scope
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

Declaration of Conformity - CE:

External Classifications and Standards

ETIM 9:
EC000011 - Control element/cover plate for domestic switching devices
ETIM 10:
EC000011 - Control element/cover plate for domestic switching devices
2CSK1032CH ABB
ABB 2CSK1032CH ABB
0.00 kr
Sold Out

Installation

Instructions and Manuals:
Mounting Type:
Flush Mounted
Type of Fastening:
Screw

Environmental

Degree of Protection:
IP55

Technical

Data Sheet, Technical Information:
Contacts Configuration:
1 NO, 0 NC
Number of Poles:
1P
Number of Main Contacts NO:
1
Number of Rocker Switches:
1
Actuator Type:
Push button
Connection Type:
Screw
Illumination:
Illuminated

Electrical

Rated Voltage (Ur):
250 V
Rated Current (In):
16 A
Number of Contacts CO:
0
Number of Contacts NC:
0
Number of Contacts NO:
1

Design

Design Range:
Chiara
Surface Finishing:
Untreated
Glossy
Untreated
Glossy
Material:
Thermoplastic
Plastic
Thermoplastic
Plastic
Legend:
Without imprint
Label Space Provided:
With Label Space
Color:
White
Number of Modules:
3

Dimensions

Width in Number of Modular Spacings:
3
Product Net Width:
66 mm
Product Net Height:
45 mm
Product Net Depth / Length:
43 mm
Product Net Weight:
0.005 kg
Built-In Depth (t2):
48 mm

Material Compliance

Conflict Minerals Reporting Template (CMRT):
WEEE Category:
5. Small Equipment (No External Dimension More Than 50 cm)
WEEE B2C / B2B:
Business To Consumer

Certificates and Declarations

Declaration of Conformity - CE:

External Classifications and Standards

ETIM 9:
EC000029 - Push button
ETIM 10:
EC000029 - Push button

Recently viewed
