1 year warranty
ACS550 4kW/5.5kW 400V 3ph AC Inverter Drive, HMI, DBr, C2 EMC
ACS380-040S-045A-4 PN: 22kW, IN: 45A; The ACS380 machinery drive comes in several variants, ensuring seamless integration into machines and connecting perfectly to automation systems. It’s a great fit for industries such as food and beverage, material handling and textile. Typical applications include mixers, conveyors, EOT and tower cranes, extruders, and textile machinery. With the integrated functional safety features, the ACS380 drive can be also part of the machine’s safety system via PROFIsafe over PROFINET, ensuring the motor is safely stopped when required. In addition, the drive’s software can be easily customized with adaptive programming to match any specific application requirements.
ACS380-040S-04A0-4 PN: 1.5kW, IN: 4A; The ACS380 machinery drive comes in several variants, ensuring seamless integration into machines and connecting perfectly to automation systems. It’s a great fit for industries such as food and beverage, material handling and textile. Typical applications include mixers, conveyors, EOT and tower cranes, extruders, and textile machinery. With the integrated functional safety features, the ACS380 drive can be also part of the machine’s safety system via PROFIsafe over PROFINET, ensuring the motor is safely stopped when required. In addition, the drive’s software can be easily customized with adaptive programming to match any specific application requirements.
ACS355 11kW 400V 3ph AC Inverter Drive, STO, C3 EMC
DRIVES 230V, 3 PHASE WITHOUT KEYPADS, 7.5KW, 31A, R4 FRAME SIZE
ACS310 HVAC IP20 15kW 400V 3ph AC Inverter Drive, C3 EMC
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
Specifications
Model |
GC-S84 |
|||
Input/output points |
Safety inputs |
8 |
||
Safety outputs |
4 (PNP) |
|||
Safety relay output |
- |
|||
AUX outputs | ||||
Test outputs |
2 |
|||
Safety input specifications |
Input device |
Contact output device or PNP output device |
||
Input type |
Type3 |
|||
ON level (voltage/current) |
Min. 11 V/2 mA |
|||
OFF level (voltage/current) |
Max. 5 V/1.5 mA |
|||
Short-circuit current |
Approx. 3 mA |
|||
Protection circuit |
Surge protection circuit, wrong wiring protection circuit |
|||
Maximum cable length |
Max. 100 m 328.1' |
|||
Safety output specifications |
Output type |
PNP transistor output (DC-13, Type 0.5, Protected outputs)*1 |
||
Maximum load current |
500 mA |
|||
Residual voltage (during ON) |
Max. 2.0 V |
|||
Leakage current (during OFF) |
Max. 0.5 mA |
|||
Maximum capacitive load |
0.5 µF |
|||
Load wiring resistance |
Max. 2.5 Ω |
|||
Protection circuit |
Overcurrent protection circuit, reverse connection protection circuit |
|||
Maximum cable length |
Max. 30 m 98.4' |
|||
Safety relay output specifications |
Output type |
- |
||
Rated load (resistance load) | ||||
Rated load (inductive load) | ||||
Relay output mechanical life | ||||
Maximum cable length | ||||
B10d | ||||
Test output specifications |
Output type |
PNP transistor output*2 |
||
Maximum load current |
100 mA*2 |
|||
Protection circuit |
Overcurrent protection circuit, reverse connection protection circuit*2 |
|||
Maximum cable length |
Max. 100 m 328.1'*3*2 |
|||
AUX output specifications |
Output type |
- |
||
Maximum load current | ||||
Residual voltage (during ON) | ||||
Leakage current (during OFF) | ||||
Protection circuit | ||||
Maximum cable length | ||||
Applicable standards |
EMC |
EMS: IEC 61131-2/-6, EN61131-2/-6,EMI: IEC 61131-2, FCC Part15B Class A, ICES-003, Class A |
||
Safety |
IEC 61508, EN 61508 SIL3, IEC62061 SIL CL3, ISO/EN 13849-1:2015 Cat. 4, PL e, UL1998 |
|||
Dimensions |
22.2×95×90 mm 0.87"×3.74"×3.54" (W×D×H) |
|||
Power supply |
Power voltage |
24 VDC (-20 to +20%) Class 2 |
||
Power consumption |
Max. 60 mA |
|||
Environmental resistance |
Ambient temperature |
−10 to +55 °C 14 to 131 °F (No freezing) |
||
Relative humidity |
5 to 85% (No condensation) |
|||
Storage temperature |
-25 to +70 °C -13 to 158 °F (No freezing) |
|||
Operating altitude |
Max. 2000 m 6561.7' |
|||
Overvoltage category |
II |
|||
Pollution degree |
2 |
|||
Vibration resistance |
Frequency: 5 to 9 Hz, Half amplitude: 3.5 mm 0.14" |
|||
Shock resistance |
Acceleration: 150 m/s2, Operating time: 11 ms, 3 times each in X, Y, Z directions |
|||
Material |
Polycarbonate |
|||
Weight |
Approx. 130 g |
|||
*1 Paragraph 6.4.6 Temporary overload of IEC 61131-2 supports up to 1.2 times the maximum load current. | ||||
Specifications
Model |
FD-XA1 |
|||
Type |
DIN rail type, main unit |
|||
Display method |
Output indicator, 4-digit 7 segment display, OLED, Stability level display |
|||
Display refresh frequency |
Instantaneous flow: approx. 5 times/second, Discharge amount/Accumulated flow approx. 30 times/second |
|||
Response time |
50 ms/100 ms/500 ms/1 s/2.5 s/5 s/10 s/30 s/60 s (selectable, default: 500 ms) |
|||
Integration data storage interval |
Written to the memory every 10 seconds |
|||
Memory back up |
EEPROM (data storage period: more than 10 years, number of data rewritable times: 1 million times or more) *1 |
|||
Detection mode |
ch.1 |
Instantaneous flow rate mode/Area mode/Pulse output (+) mode/Integrated flow mode/Shot mode (selectable) |
||
ch.2 |
Instantaneous flow rate mode/Area mode/Pulse output (-) mode/Shot mode/Error output mode/Bubble alert mode/Error + bubble alert mode (selectable) |
|||
Input/output |
Output |
NPN/PNP setting switch |
||
Analog output |
4-20 mA/0-20 mA (selectable) load resistance: 500 ohms or lower |
|||
External input |
Flow rate zero input/shot sampling input/integrated flow reset input/zero shift input (selectable) |
|||
Network support |
IO-Link*3 |
|||
Unit expansion |
Up to 7*4 per main unit |
|||
Protection circuit |
Power supply reverse connection protection, power surge protection, output short circuit protection, output surge protection |
|||
Power supply |
Power voltage |
20 to 30 VDC including 10 % ripple (P-P) , Class 2 |
||
Power consumption |
195 mA or lower (including the sensor head, excluding the load current) |
|||
Environmental resistance |
Ambient temperature |
-10 to +50 °C (No freezing) 14 to 122 °F |
||
Relative humidity |
35 % to 85 %RH (No condensation) |
|||
Vibration resistance |
10 - 55 Hz, double amplitude 1.5 mm 0.06 ", 2 hours each for X,Y,Z direction |
|||
Shock resistance |
100 m/s2 (approx. 10 G) 16 ms pulse, 1000 times each for X,Y,Z direction |
|||
Material |
Main body case/front sheet: PC, Key top: POM, Cable: PVC |
|||
Weight |
Approx. 210 g |
|||
*1 Internal data from full time recording can be read via USB (Ver.2.0) communication. | ||||
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
Description
The EVF9325-EV controller by Lenze is a vector frequency inverter. It is a member of the high-performance motor control 9300 series of inverters, which are utilized in industrial automation applications. It runs the operation with a primary circuit voltage supply of 3 phases of 400 volts AC at 50/60 hertz rated frequency. It has an output voltage range of 0 to 400 volts AC, and with mains choke or filter, it can handle a mains current rate of 15 amps. It supports a mains choke, a separate electromagnetic brake, and filtering interference. Additionally, it contains a 4 pole ASM type motor with a 7.5kW (750 watts) motor power rating. The EVF9325-EV's AC mains connector is a 3 phases 320 volts AC connection. The 45 to 65 hertz mains voltage frequency range is specified to allow flexibility in adjusting to various input frequencies. Alternatively, a DC power supply with a voltage rating of 460 volts DC power or 620 volts DC supply can be used to power the servo inverter. This offers a different power option for particular applications. The EVF9325-EV develops to install on fixing rails, and it comes with four fixing rails for a safe installation. The temperature sensitivity range for the EVF9325-EV is 0 to 40 degrees Celsius. The EVF9325-EV is small, with a width of 139 mm and a height of 350 mm, helping good use of the space. The inverter has a power loss rating of 260 watts, the amount of energy lost as heat while it works.
Technical specifications for EVF9325-EV
| Manufacturer | Lenze |
|---|---|
| Product ID | evf9325-ev |
| Series | 9300 series |
| Type | Vector Frequency Inverter |
| Main circuit voltage input | 400 VAC, 50/60 Hz |
| Voltage type | 3-phase |
| Output voltage | 0-400 VAC |
| DC mains connection option | 460 V, 620 V |
| Mains choke | Supported |
| Motor power rating | 7.5 kW with 4-pole ASM |
| Mains current with choke | 15 amps |
| Weight | 7.8 kg |
| Power loss rating | 260W |
PLC Direct is not an authorized distributor. We offer a broad range of in-stock products with minimal lead time.
Specifications
Model |
PZ-G61N |
|||
Type |
Retro-reflective *1 |
|||
Shape |
Rectangular |
|||
Output |
NPN |
|||
Cable connection |
Cable (2 m 78.74") *2 |
|||
Detecting distance |
0.1 to 4.2 m |
|||
Spot diameter |
― |
|||
Light source |
Red LED |
|||
Sensitivity adjustment |
1-turn trimmer (230°) |
|||
Response time |
500 µs |
|||
Operation mode |
LIGHT-ON/DARK-ON (switch-selectable) |
|||
Indicators (LED) |
Output: Orange LED, |
|||
Control output |
Open collector output, 30 V max., 100 mA max., Residual voltage: 1 V max. |
|||
Protection circuit |
Reversed polarity, overcurrent protection, surge absorber |
|||
Interference suppression |
Up to 2 units |
|||
Tightening torque |
Rectangular models (Mounting hole part): 0.5 N m max. |
|||
Rating |
Power voltage |
10 to 30 VDC, including Ripple (P-P) 10 % |
||
Current consumption |
34 mA or less |
|||
Environmental resistance |
Enclosure rating |
IEC: IP67/NEMA: 4A, 6, 12/DIN: IP69K |
||
Ambient light |
Incandescent lamp: 5,000 lux max., Sunlight: 20,000 lux max. |
|||
Ambient temperature |
-20 to +55 °C -4 to 131 °F (No freezing) |
|||
Relative humidity |
35 to 85 % RH (No condensation) |
|||
Vibration resistance |
10 to 55 Hz, Double amplitude 1.5 mm 0.06", 2 hours in each of the X, Y, and Z directions |
|||
Shock resistance |
1,000 m/s2, 6 times in each of the X, Y, and Z directions |
|||
Material |
Housing, M18 nut |
Glass-fiber reinforced PBT |
||
Lens cover |
Acrylic |
|||
Trimmer |
Glass-fiber reinforced polyamide (PA) |
|||
Case connection |
Screw: Nickel-plated iron and zinc, packing: nitrile butadiene rubber (NBR) |
|||
Cable (cable models only) |
Polyvinyl chloride (PVC) |
|||
Connector (connector type with cable only) |
― |
|||
Accessories |
Instruction manual |
|||
Weight |
Rectangular cable models: Approx. 60 g (Thrubeam-models transmitter: Approx. 50 g) |
|||
*1 Cable sold separately for connector models/pigtail quick disconnect models. Reflector sold separately for retro-reflective models. | ||||
